Mbombe 4 South African 4x4 Mine Resistant Ambush Protected (MRAP)
Mbombe 4
Mine-Resistant Ambush Protected (MRAP)
Other
Basic Information
Name
Mbombe 4 South African 4x4 Mine Resistant Ambush Protected (MRAP)
Designation
Mbombe 4
Alternate Designation
Mbombe 4
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
Paramount Group
Date of Introduction
2021
Description
The Mbombe 4 South African 4x4 Mine Resistant Ambush Protected (MRAP) is designed to provide a user with a platform that can provide protection for personnel during routine duties such as patrols in a hostile environment where heavily armed assets are not an anticipated threat. It is produced under licence in India by Bharat Forge as the Kalyani M4 and has been proposed for licensed production in Thailand as the D-Lion.
Ground Specifications
Crew
3
Mobility Type
Wheeled (4x4)
Engine
Turbocharged Diesel (450 hp)
NBC Protection
Yes
Max Speed
140.0 km/h
Range
800.0 km
Variants
Mbombe 4 S
The Mbombe 4 S is comparable in most respects to the standard Mbombe 4, but features several modifications designed to improve the vehicle's ability to operate in austere desert environments. These include changes to the air conditioning system and fuel system, the addition of a front bumper with an integral winch, changes to the rear door to allow for a spare tire to be carried, and interior changes to include additional storage space and improved access.
System
Alternative Designation
Mbombe 4
Type
Mine Resistant Ambush Protected (MRAP)
Manufacturer
Paramount Group
Configuration
4x4
Crew
3 ea
Payload Capacity
2,700 kg that includes occupants, fuel, weapons, ammunition, and other equipment.
Note
The Mbombe 4 is fitted with an onboard mission computer and interface system that is designed to integrate both Western and Eastern-made weapon systems. The vehicle is also capable of carrying the latest generation navigational systems, such as a driver-assist camera system, vehicle location and tracking system, radios, and intercoms.
Dimensions
Length
6.130 m
Width
2.60 m
Height
2.450 m
Weight, Standard
13,300 kg
Weight, Combat
16,000 kg
Automotive
Engine Name
Cummins, 6 cylinders
Engine Type
Turbocharged and Intercooled Diesel
Engine Power
450 hp
Maximum Range
800 km
Maximum Speed
140 km/h
Amphibious
No
Gradient
60%
Side Slope
35%
Vertical Step
0.5 m
Fording
0.9 m
Angle of Approach
44°
Angle of Departure
43°
Main Weapon System
Note
The Mbombe 4 can be fitted with a roof hatch to access roof-mounted weapon stations, or it can accommodate a variety of turrets. Imagery released by Paramount shows that one option is the Snake Head Mk II protected weapon station from Jordan. The weapon station is enclosed from all sides and has a roof, offering the operator nearly 360° of armoured protection. The Snake Head Mk II, can be armed with a variety of weapons, including a 14.5 mm KPV HMG, 12.7 mm DShK HMG, 12.7 mm (.50 calibre) M2 HB MG, 7.62 mm FN MAG MG, 7.62 mm M240 MG, 7.62 mm PKM MG, and 5.56 mm FN Minimi. The weapon station is also equipped with three sliding firing ports, 11×20 cm in size, from which small arms can be fired. Elevation is from -10° to +50°.
Protection
Armor
The Mbombe 4 utilizes a steel monocoque hull, which provides ballistic protection from small-arms fire up to STANAG 4569 Level 3. The hull is V-shaped and the level of blast protection is rated to STANAG 4569 Level 4a (10 kg TNT equivalent under each wheel) and 4b (10 kg TNT equivalent under the hull). Paramount has also stated that the vehicle provides protection against a side blast or roadside bomb to the equivalent of 50 kg of TNT.
Applique Armor
The vehicle could be fitted with applique armor packages to provide a higher level of ballistic protection up to STANAG 4569 Level 4, as well as higher levels of mine protection if required, although this would be limited by the vehicle's payload of 2.7 tons.
NBC Protection
Yes
Smoke Equipment
Yes
Image Sources
Details
Country of Origin
South Africa
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
M
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.13 m
Width
2.6 m
Height
2.45 m
Weight
16000 kg
Operators (4)
India
South Africa
Congo, Republic of the
Togo
