Supacat 400 British 4x4 Armored Personnel Carrier (APC)

Supacat 400

Amphibious Armored Personnel Carrier (APC)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Supacat 400 British 4x4 Armored Personnel Carrier (APC)
Designation
Supacat 400
Alternate Designation
Supacat 400; SPV-400
Equipment Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Supacat
Date of Introduction
2008
Description

The Supacat Protected Vehicle 400 (SPV 400) is a further evolution of Supacat’s long pedigree of developing relevant and effective military vehicles. Giving soldiers what they need for 21st century operations: superior mobility and protection. Building on previous experience and integrating direct feedback from the operational use of our existing fleet, the SPV 400 takes the performance levels of lightweight protected mobility platforms beyond that currently on offer around the globe. “Fully integrated protection” is the key to the SPV formula which, combined with a cutting edge bespoke automotive solution, offers exceedingly high levels of protection yet remains sufficiently packaged to access the tightest of terrain. The SPV 400 mirrors the “go anywhere” ethos of other Supacat products and provides supreme cross-country performance as well as providing the protection required to operate in an urban environment. The operator’s needs and the integration of modern battlefield systems have been considered from the outset so the SPV 400 is a highly attractive and ‘useable’ solution for 21st Century operations. The SPV 400 patrol variant can be adapted for use by fitting alternative and interchangeable mission pods that include ambulance, logistic, command and open top weapon mounted variants.

Ground Specifications
Crew 2
Mobility Type Wheeled (4x4)
Engine 4.5-liter, 4-cyl diesel (180 hp)
Active Protection None
NBC Protection Yes
Max Speed 120.0 km/h
Range 600.0 km
Variants
SPV-600 This is a 6 x 6 variant planned by Supacat with increased volume and payload.
System
Alternative Designation Supacat 400; SPV-400
Type Armored Personnel Carrier (APC)
Manufacturer Supacat Ltd., Honiton, U.K.
Family Supacat
Crew 2 ea
Passenger Capacity 4 ea
Dimensions
Length 5.36 m
Width 2.06 m
Height 2.57 m
Track 1.62 m
Wheelbase to 2nd axle 3.15 m
Front Overhang 1.08 m
Rear Overhang 1.14 m
Maximum Ground Clearance 0.38 m
Minimum Ground Clearance 0.08 m
Gross Weight 2,000 kg
Payload Weight 2,000 kg
Automotive
Engine Name 1 x Cummins
Engine Type 4.5-liter, 4-cyl diesel
Engine Power 180 hp
Cruising Range 600 km
Speed, Maximum Road 120 km/h
Speed, Average Cross INA
Speed Maximum Swim Not Amphibious
Fording Depth 0.75 m
Gradient 60 percent
Side Slope 34 percent
Turning Circle, Curb-to-Weight 11.70 m
Turning Circle, Wall-to-Wall 12.7 m
Approach Angle 40 deg
Departure Angle 38 deg
Ramp over Angle 155 deg
Protection
Hull Armor Protection from small arms fire and shell splinters
Turret Armor INA
Applique Armor Available
Explosive Reactive Armor No
Active Protection System No
Mine Clearing No
NBC Protection Yes
Smoke Equipment INA
Details
Country of Origin United Kingdom
Category Land
Land
Filter Label
S
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.36 m
Width
2.06 m
Height
2.57 m
Weight
2000 kg
Operators (1)
United Kingdom
