Galicia

Galicia

Amphibious Assault Ships
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Galicia
Designation
Galicia
Alternate Designation
Rotterdam
Equipment Type
Amphibious Assault Ships
Manufacturer
Navantia, Royal Schelde Group
Date of Introduction
1998
Description

The Galicia/Rotterdam-class ships were designed jointly by Spain and the Netherlands with minor differences between both ships. These ships will perform amphibious assault, troops transport, logistics support, and anti-submarine warfare missions. Galicia/Rotterdam-class ships have been designed to operate helicopters but V/STOL fixed-wing aircraft such as the Harrier and F-35C may be eventually operated from them. The Spanish Navy ordered two Galicia-class ships built by IZAR, formerly Bazan, and delivered in 1998 and 2001. The Royal Dutch Navy ordered a single Rotterdam-class ship built by Royal Schelde Shipyard and delivered in 1998. The Galicia-class ships are able to transport and disembark a fully equipped battalion of Marines using helicopters and LCUs to the enemy shore. These vessels have extended facilities for medical and surgical care. Two Goalkeeper, Galicia-class 2 Meroka, close-in weapon system (CIWS) have been supplied for ship self-defense as well as ESM equipment, etc. They can accommodate Merlin (4), NH90 (6), Sea King (4), and AB-212 (6) helicopters and transport 130 armored vehicles or 33 MBTs.

Naval & Littoral Specifications
Crew 128
Displacement 13000.00 tonnes
Beam 25.00 m
Max Speed 19.0 knots
Overview (Deagel)
Group Amphibious Assault Ships
Status Active
Also Known As Rotterdam
Origin Netherlands, Spain
Contractors Navantia, Royal Schelde Group
Initial Operational Capability (IOC) 1998
Total Production 3
Specifications (Deagel)
Crew 128
Troops 611
Dimensions — Beam 25 meter
Dimensions — Length 160 meter
Mass — Full Displacement 13,000 ton
Performance — Max Range 11,112 kilometer
Speed — Cruise Speed 6.2 mps
Speed — Top Speed 9.8 mps
Gear (Deagel)
Item 1 ASW Helicopters: EH101 Merlin (4)
Item 2 ASW Helicopters: NH90 NFH (6)
Item 3 Landing Crafts: LCM-1E (4)
Item 4 Landing Crafts: LCU (4)
Item 5 Sea-Based Air Defense Systems: Goalkeeper (2)
Details
Country of Origin Netherlands
Category Landing Ships and Amphibious Assault Ships
Naval > Landing Ships and Amphibious Assault Ships
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
160 m
Width
25 m
Height
Weight
13000000 kg
Operators (2)
Spain
Netherlands
