Priz Class (Project 1855 Class) Russian Deep Submergence Rescue Vehicle

Priz Class

Deep Submergence Rescue Vehicle

Spotted an error? Sign in to suggest an edit.

Basic Information

Name

Priz Class (Project 1855 Class) Russian Deep Submergence Rescue Vehicle

Designation

Priz Class

Alternate Designation

Priz Class; Project 1855 Class

Equipment Type

Deep Submergence Rescue Vehicle

Manufacturer

Krasnoe Sormovo

Date of Introduction

1986

Description

Priz Class (Project 1855 Class) Russian Deep Submergence Rescue Vehicles a type of Deep Submergence Rescue Vehicle (DSRV) operated by the government of Russia. There are known to be at least five vessels of the class, several of which were involved in the failed rescue attempt when the Kursk sank on 12 August 2000. The Russian word "Priz" (“приз”) means "prize". The Priz is thought to be operable either manned or unmanned with a battery endurance of three hours. Over the 2006-2016 years, an upgrade of the class to improve its navigational, search, and life-support ability was conducted. The Priz submarines are carried by Pionier Moskvyy class submersible support ships (Project 05360/05361), which can carry up to two of the submarines. The ships are equipped with special equipment to deploy Priz in rough seas.

Naval & Littoral Specifications

Crew 4

Beam 3.80 m

Draft 3.90 m

Variants

AS-26 Commissioned: 1986 Status: Active Fleet: Baltic Fleet

AS-28 Commissioned: 1989 Status: Active Fleet: Black Sea Fleet

AS-30 Commissioned: 1989 Status: Active Fleet: Black Sea Fleet

AS-34 Commissioned: 1991 Status: Active Fleet: Baltic Fleet

System

Alternative Designation Priz Class; Project 1855 Class

Type Deep Submergence Rescue Vehicle

Builder Krasnoe Sormovo

Crew 4 ea

Passengers 20 ea

Manipulator Arms The Priz vessels are equipped with manipulators that can lift up to 50 kg.

Note A Project 1855 Priz Deep-Diving Rescue Vehicle was involved in the Kursk accident. It was much-needed in the aftermath of the accident with Kursk submarine. On the morning of 13 August 2000, the submarine of the Main Intelligence Department investigated the KURSK bow. At 18:00 and 18:30 were carried out the first two descents of a diving bell from ALTAY rescue ship. At 19:30 Project 1855 DSRV from MIKHAIL RUDNITSKIY discovered by sight the submarine laid on the seabed. At night on 15 August 2000, the Kursk submarine's bow was inspected for the first time by a deep submergence vehicle, which obtained data about the damage to the bow. It was determined that two fore compartments had been flooded. The next morning the rescue operation was temporarily halted the storm that had begun that night. Only when the weather had improved did the attempts of diving and docking of DSRV were started with two PRIZ-type vehicles. The first diving lasted from 20:00 till 5:30 (four unsuccessful docking attempts). That day the surviving crew members of the Kursk stopped sending distress signals.

Dimensions

Length 13.5 m

Beam 3.8 m

Draft 3.9 m

Displacement, Surfaced INA

Displacement, Submerged 55 tons

Propulsion System

Engine Name INA

Engine Type Diesel-Electric

Engine Power INA

Maximum Range 39 km

Maximum Speed 3.3 knots (6.1 km/h)

Cruise Speed 2.3 knots (4.3 km/h)

Ascent Speed 0.5 metres per second

Test Depth 1,000 m

Endurance 120 hours with 4 aboard; or 10 hours with 24 aboard.

Navigation System

Navigation Complex 1 x MSTA-M-AS navigation complex.

Sonar Systems

Sonar #1 1 x MGA-19 Krilyon sonar.

Sonar #2 1 x MGS-22 Gletcher sonar.

Communications

Communication System 1 x MGA-25 Protey-6 underwater communications system.

Protection

Hull Titanium hulled vessel.

Countermeasures No

NBC Water Washdown System INA

EW Intercept No

Image Sources

Note https://www.micoope.com.gt/?o=dsrv-as-28-priz-n-Nj5ng6Tz; https://eng.mil.ru/en/structure/forces/airborne/more/photo/gallery.htm?id=36340@cmsPhotoGallery

Details

Country of Origin Russia

Category Submarines

Naval > Submarines

Classification

Domain

Naval & Littoral

Equipment Status

Active

Dimensions

Length

13.5 m

Width

3.8 m

Height

—

Weight

55000 kg

Operators (1)

Russia
