EVO Nano Chinese Unmanned Aerial Vehicle (UAV)
EVO Nano
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
EVO Nano Chinese Unmanned Aerial Vehicle (UAV)
Designation
EVO Nano
Alternate Designation
EVO Nano
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Autel Robotics
Date of Introduction
2019
Description
The EVO Nano Chinese Unmanned Aerial Vehicle (UAV) is packed a 1/1.28-inch(0.8-inch) CMOS sensor capable of 50 MP photos. A RYYB color filter array design with a large aperture of f/1.9 offers superior noise reduction capabilities and the power to effortlessly produce quality images in low- light conditions. Track fast-moving subjects with incredible precision through PDAF + CDAF autofocus system; Squeeze rich detail from shadows and highlights no matter how extreme the lighting conditions using HDR mode, which rapidly snaps several photos at different exposures so they can be stitched together in post-production.
Air & Air Defense Specifications
Engine
Battery
System
Alternate Designation
EVO Nano
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
Autel Robotics
Autonomy
Semi-Autonomous
Crew
Unmanned
Operating Frequency
2.400-2.4835GHz，5.725-5.850GHz,5.150-5.250GHz
Transmission Power (EIRP)
FCC: ≤30dBm；CE: ≤20dBm
GNSS
GPS, GLONASS, Galileo
Operating Temperature
0°C ~ 40°C
Launching System
Vertical Take-Off and Landing (VTOL)
Recovery System
Vertical Take-Off and Landing (VTOL)
Dimensions
Length, Folded
142 mm
Width, Folded
94 mm
Height, Folded
55 mm
Length, Unfolded
260 mm
Width, Unfolded
325 mm
Height, Unfolded
55 mm
Wheelbase
231 mm
Maximum Takeoff Weight (without accessories)
249 g
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Max Ascent Speed
5m/s (ludicrous), 4m/s (standard), 3m/s (smooth)
Max Level Flight Speed
4m/s (ludicrous), 3m/s (standard), 2m/s (smooth)
Max Level Flight Speed(no wind, near sea level)
15m/s (ludicrous), 10m/s (standard), 5m/s (smooth)
Max Takeoff Altitude
4,000 m
Max Flight Time (no wind)
28 min
Max Hovering Time (no wind)
26 min
Max Flight Distance (no wind)
16.8km
Max Wind Resistance
Level 5
Hovering Accuracy
Vertical: ±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal: ±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning);
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
E
Classification
Domain
Air & Air Defense
Equipment Status
Active
Operators (1)
China
