Panhard AML-90 French 90mm Self-Propelled Gun (SPG)
Panhard AML-90
Self-Propelled Gun (SPG)
Other
Basic Information
Name
Panhard AML-90 French 90mm Self-Propelled Gun (SPG)
Designation
Panhard AML-90
Alternate Designation
Panhard AML-90
Equipment Type
Self-Propelled Gun (SPG)
Manufacturer
Panhard
Date of Introduction
1961
Description
The Panhard AML-90 French 90mm Self-Propelled Gun (SPG) is a direct fire support variant of the AML family. It is armed with a large-caliber gun designed to be used against armored vehicles and emplacements.
Ground Specifications
Crew
3
Mobility Type
Wheeled (4x4)
Main Weapon
90 mm
Engine
4-Cylinder Gasoline (90 hp)
NBC Protection
Yes
Max Speed
90.0 km/h
Range
600.0 km
System
Alternative Designation
Panhard AML-90
Type
Self-Propelled Gun (SPG)
Caliber
90 mm
Manufacturer
Panhard
Configuration
4x4
Crew
3 ea
Dimensions
Length
5.11 m
Width
1.97 m
Height
2.07 m
Weight, Combat
5,500 kg
Ground Clearance
0.33 m
Automotive
Engine Name
Panhard Model 4 HD
Engine Type
4 cylinders, air-cooled, petrol
Engine Power
90 hp at 4,700 rpm
Power-to-Weight Ratio
16.36 hp/t
Maximum Range
600 km
Maximum Speed
90 km/h
Amphibious
No
Gradient
60%
Side Slope
30%
Vertical Step
0.3 m
Trench
0.8 m
Main Weapon System
Note
1 × turret-mounted 90 mm
Coaxial Weapon System
Note
1 × coaxial-mounted 7.62 mm machine gun
Protection
Hull Armor
steel 8 mm
Turret Armor
steel 12 mm
Applique Armor
Yes
NBC Protection
Yes
Smoke Equipment
4 × turret-mounted 80 mm smoke-grenade launcher (2 × 2)
Image Sources
Details
Country of Origin
France
Category
Self-Propelled Gun/Howitzer Artillery Systems
Land > Artillery > Self-Propelled Gun/Howitzer Artillery Systems
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.11 m
Width
1.97 m
Height
2.07 m
Weight
5500 kg
Operators (28)
Argentina
Bahrain
Burkina Faso
Burundi
Cameroon
Chad
Djibouti
Ecuador
El Salvador
Gabon
Guinea
Kenya
Lebanon
Lesotho
Malaysia
Mauritania
Morocco
Niger
Nigeria
Rwanda
Saudi Arabia
Senegal
Somalia
Sudan
Togo
Tunisia
Venezuela
Yemen
