Taian TA4410 (TAS4410) Chinese 8x8 Tank Transporter
Taian TA4410
Tank Transporter
Other
Basic Information
Name
Taian TA4410 (TAS4410) Chinese 8x8 Tank Transporter
Designation
Taian TA4410
Alternate Designation
Taian TA4410
Equipment Type
Tank Transporter
Manufacturer
Taian Special Vehicle Company
Date of Introduction
1997
Description
The Taian TA4410 Chinese 8x8 Tank Transporter is produced by Taian Special Vehicle Company. This vehicle is used by the Chinese military. This tank transporter has also been exported to Venezuela.
Ground Specifications
Crew
6
Mobility Type
Wheeled (8x8)
Engine
Diesel (517 hp)
Max Speed
71.0 km/h
Range
800.0 km
System
Alternative Designation
Taian TA4410
Type
Tank Transporter
Manufacturer
Taian Special Vehicle Company
Configuration
8x8
Cab Seating
1 + 5
Payload Capacity
65 tons
Winch
There are winches at the back of the cab for loading operations. These are used to load disabled or immobile vehicles.
Dimensions
Length
9.0 m
Width
3.3 m
Height
3.2 m
Weight, Empty
21 tons
Weight, Gross Combination
98 tons
Automotive
Engine Name
Deutz
Engine Type
Diesel
Engine Power
517 hp
Range
800 km
Speed, Maximum Road
71 km/h
Speed Maximum Swim
Not Amphibious
Gradient, Empty
60%
Gradient, Loaded
28%
Side Slope
28%
Vertical Step
INA
Trench
INA
Fording
1.2 m
Main Weapon System
Note
There are no crew-served weapons mounted on the Taian TA4410 Chinese 8x8 Tank Transporter.
Protection
Armor
INA
Applique Armor
INA
NBC Protection
INA
Smoke Equipment
No
Details
Country of Origin
China
Category
Transportation
Land > Combat Support Vehicles > Transportation
Filter Label
T
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
9 m
Width
3.3 m
Height
3.2 m
Weight
98000 kg
Operators (2)
China
Venezuela
