2S9
2S9
Self-Propelled Howitzers
Basic Information
Name
2S9
Designation
2S9
Alternate Designation
2S9-1, Anona, Nona-S
Equipment Type
Self-Propelled Howitzers
Manufacturer
TsNIITochMash
Date of Introduction
1981
Description
The 2S9 Anona or Nona-S is a 120mm amphibious self-propelled mortar/howitzer based on an stretched version of the BMD tracked chassis. It was fielded by the Soviet Army in the mid-1980s. The 2S9 is powered by a 5D20 diesel engine developing 240 hp and provides a maximum speed of 60 kph on land. Besides the amphibious Nona-S is equipped with two rear waterjets for use on water. The turret with the equipped with 120mm cannon is operated by a two-man crew. 2S9 crew consists of driver, gunner, loader and commander. The 120mm gun can fire as a howitzer or as a mortar having a maximum range of more than 12 kilometers firing rocket assisted rounds.
Ground Specifications
Crew
4
Mobility Type
Tracked
Main Weapon
120mm cannon (120mm)
Max Speed
60.0 km/h
Range
500.0 km
Overview (Deagel)
Group
Self-Propelled Howitzers
Status
Active
Also Known As
2S9-1, Anona, Nona-S
Origin
Russia
Contractor
TsNIITochMash
Initial Operational Capability (IOC)
1981
Total Production
?
Specifications (Deagel)
Ammunition Load
40
Crew
4
Rolling Rubber Wheels
6
Dimensions — Height
2.3 meter
Dimensions — Length
6 meter
Dimensions — Main Gun Caliber
120 millimeter
Dimensions — Width
2.6 meter
Mass — Combat Weight
8,700 kilogram
Performance — Main Gun Max Range
12,800 meter
Performance — Main Gun Min Range
1,700 meter
Performance — Max Range
500 kilometer
Power — Power
240 hp
Rate — Max Rate of Fire
10 roundperminute
Rate — Sustained Rate of Fire
4 roundperminute
Speed — Top Speed
60 kph
Variants
Variant 1
2S9
Variant 2
BMD-3
Variant 3
BMD-4
Variant 4
BMD-4M
Variant 5
BTR-MD Rakushka
Variant 6
Ptitselov
Details
Country of Origin
Russia
Category
Artillery
Land > Artillery
Sources
deagel.com: https://www.deagel.com/x/x/a000665
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6 m
Width
2.6 m
Height
2.3 m
Weight
8700 kg
Operators (6)
Russia
China
Ukraine
Soviet Union
Kyrgyzstan
Turkmenistan
