AC-130U Spooky

AC-130U Spooky

Gunship Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
AC-130U Spooky
Designation
AC-130U Spooky
Alternate Designation
AC-130W (latest variant equipped with GAU-23 cannon)
Equipment Type
Gunship Aircrafts
Manufacturer
Lockheed Martin
Date of Introduction
1995
Description

The AC-130H Specter and AC-130U Spooky have been designed to provide close air support, air interdiction and force protection. These heavily armed aircraft include side-firing weapons integrated with sophisticated sensors (SAR, CCD-TV and IR), navigation and fire control systems to provide surgical firepower during extended loiter periods, at night and in adverse weather. The AC-130U is the most advanced gunship aircraft in the world and can attack two targets simultaneously. The AC-130 aircraft were first introduced in Vietnam scoring 10,000 Vietnamese trucks and many US soldiers while providing close air support. Subsequently they were employed in Operation Urgent Fury in Grenada in 1983, Operation Just Cause in Panama in 1989, and Operation Enduring Freedom in Afghanistan in 2001. The AC-130U Spooky aircraft can be armed with one 105mm cannon in addition to one 40mm, and one additional 25mm guns. The US Air Force operates a fleet of 13 AC-130U gunships. The US Air Force and Boeing selected Lockheed-Martin's Gunship Multispectral Sensor System (GMS2) to replace ALLTV sensor onto US Air Force's AC-130Us. The development contract valued at $10.7 million was awarded on January 11, 2005. The program total value could amount to $35 million including production options. GMS2 will be integrated onto for four new AC-130U aircraft bought by the Air Force. The Boeing company expects to deliver the first of four AC-130Us ordered by the Air Force Special Operations Command (AFSOC) in 2006. These aircraft were chosen by AFSOC due to their capabilities in support of operational missions in the global war on terrorism.

Air & Air Defense Specifications
Crew 13
Max Speed 478.8 km/h
Range 2408.0 km
Service Ceiling 7620 m
Wingspan 40.40 m
Overview (Deagel)
Group Gunship Aircrafts
Status Active
Also Known As AC-130W (latest variant equipped with GAU-23 cannon)
Origin United States of America
Contractor Lockheed Martin
Initial Operational Capability (IOC) 1995
Total Production 17
Unitary Cost USD $81 million
Specifications (Deagel)
Crew 13
Number of Engines 4
Dimensions — Height 11.7 meter
Dimensions — Length 29.8 meter
Dimensions — Main Gun Caliber 105 millimeter
Dimensions — Wingspan 40.4 meter
Mass — Max Takeoff Weight 70,308 kilogram
Performance — Ceiling 7,620 meter
Performance — Max Range 2,408 kilometer
Power — Max Power at TakeOff 19,640 shp
Speed — Top Speed at High Altitude 133 mps
Gear (Deagel)
Item 1 ESM & Warning Systems: AN/ALR-69 (1)
Item 2 Jamming Systems: AN/ALQ-172 (1)
Item 3 Jamming Systems: AN/ALQ-196
Item 4 Medium Caliber Cannons: GAU-12/U
Item 5 Medium Caliber Cannons: GAU-23
Item 6 Optronic Systems: AN/AAQ-26 (1)
Item 7 Optronic Systems: AN/AAQ-39 GMS2 (1)
Item 8 Radar Systems: AN/APQ-180 (1)
Item 9 Radar Systems: AN/ASQ-236 Dragon's Eye (1)
Item 10 Turboprop Engines: T56-A-16 (4)
Variants
Variant 1 C-130H Hercules
Variant 2 MC-130H Talon II
Variant 3 AC-130U Spooky
Variant 4 C-130J Super Hercules
Variant 5 CC-130J Super Hercules
Variant 6 KC-130J Super Hercules
Variant 7 WC-130J
Variant 8 MC-130W Combat Spear
Variant 9 EC-130J Commando Solo
Variant 10 MC-130J Commando II
Variant 11 AC-130J Ghostrider
Variant 12 LM-100J
Variant 13 C-130J-SOF
Details
Country of Origin United States
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
29.8 m
Width
40.4 m
Height
11.7 m
Weight
70308 kg
Operators (1)
United States
