CV-22B Osprey

CV-22B Osprey

VTOL Military Transport Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
CV-22B Osprey
Designation
CV-22B Osprey
Alternate Designation
CV-22A Osprey (original designation)
Equipment Type
VTOL Military Transport Aircrafts
Manufacturer
Boeing, Textron
Date of Introduction
2009
Description

The CV-22A will conduct long range special operations missions. The US Air Force plans to purchase up to 50 CV-22s through 2017 with an initial operational capability (IOC) planned for 2009. The first operational CV-22 will be handed over to the US Air Force December 2006 at Hurlburt Field, Florida. According to 2004 official reports, the USMC MV-22 initial operational capability (IOC) will be delayed from September 2004 to March 2007, and the US Air Force CV-22 is expected to complete its initial operational test and evaluation in September 2007 (June 2006 originally). Bell-Boeing joint program office received a $850 million acquisition contract for long lead effort and materials associated with the manufacture and delivery of 11 fiscal year 2006 Lot 10 low rate initial production (LRIP) V-22 aircraft January 24, 2005. Lot 10 includes 9 MV-22 for the Marine Corps and two CV-22s for the Air Force. In February 2005, the US Air Force received its third CV-22 Osprey tilt-rotor test aircraft at Edwards Air Force Base, California. These three aircraft were planned to undergo operational testing beginning in summer 2006. CV-22s will be modified to perform as Special Operations Command aircraft through night flying, low altitude operations in bad weather, and research and rescue (SAR). On 27 December 2005, Bell-Boeing Joint Program Office was awarded a $1.06 billion contract by the US Navy for procurement of 14 fiscal year 2007 Lot 11 MV-22 and 2 Lot 11 CV-22 aircraft. The 16 V-22 aircraft were expected to be delivered before September 2009. In March 2006 the United States Air Force took delivery of the first operational CV-22 Block 10 aircraft paving the way for an initial operational capability in 2009. As of 2006 the US Air Force plans to procure up to 50 CV-22 Ospreys to be delivered to the Air Force Special Operations Command (AFSOC) by 2017.

Air & Air Defense Specifications
Crew 2
Max Speed 511.2 km/h
Range 3889.0 km
Service Ceiling 7925 m
Wingspan 25.60 m
Overview (Deagel)
Group VTOL Military Transport Aircrafts
Status Active
Also Known As CV-22A Osprey (original designation)
Origin United States of America
Contractors Boeing, Textron
Initial Operational Capability (IOC) 2009
Total Production 50
Unitary Cost USD $116 million
Specifications (Deagel)
Crew 2
Number of Engines 2
Troops 24
Dimensions — Height 6.6 meter
Dimensions — Length 17.5 meter
Dimensions — Main Gun Caliber 12.7 millimeter
Dimensions — Wingspan 25.6 meter
Mass — Cargo 9,072 kilogram
Mass — Empty Weight 15,032 kilogram
Mass — Max Takeoff Weight 27,443 kilogram
Performance — Ceiling 7,925 meter
Performance — Max Range 3,889 kilometer
Performance — Min Range 954 kilometer
Power — Max Power at TakeOff 12,300 shp
Speed — Top Speed at High Altitude 142 mps
Gear (Deagel)
Item 1 Decoy Systems: AN/ALE-47
Item 2 ESM & Warning Systems: AN/AAR-47 (1)
Item 3 Jamming Systems: AN/AAQ-24 Nemesis
Item 4 Jamming Systems: AN/ALQ-211 SIRFC (1)
Item 5 Optronic Systems: AN/AAQ-16 (1)
Item 6 Radar Systems: AN/APQ-186 (1)
Item 7 Radar Systems: Silent Knight
Item 8 Tactical Vehicles: LSV (1)
Item 9 Turboprop Engines: AE 1107C (2)
Item 10 Weapon Stations: Remote Guardian System (1)
Variants
Variant 1 MV-22C Osprey
Variant 2 CV-22B Osprey
Variant 3 HV-22A Osprey
Variant 4 CMV-22B Osprey
Variant 5 E-2D AHE CV-22B
Details
Country of Origin United States
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
17.5 m
Width
25.6 m
Height
6.6 m
Weight
27443 kg
Operators (1)
United States
