WC-130J

WC-130J

Surveillance & Reconnaissance Airplanes
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
WC-130J
Designation
WC-130J
Alternate Designation
Hurricane Hunter (nickname), WeatherBird (nickname)
Equipment Type
Surveillance & Reconnaissance Airplanes
Manufacturer
Lockheed Martin
Date of Introduction
2005
Description

The C-130J achieved initial operational capability in 1999. The WC-130J is a derivative of the C-130J tactical transport aircraft specially modified to perform weather reconnaissance missions. The 53rd Weather Reconnaissance Squadron at Keesler Air Force Base in Missouri received eight aircraft in 1999 and two more in 2000 totaling 10 WC-130Js. Assigned to hurricane hunting the new aircraft has 29 percent more thrust than those it replaced, which means WC-130J can fly higher and faster. It can reach 28,000-ft (8,500 meters) in 14 minutes and it's a lot more fuel efficient than its predecessor allowing to go farther. WC-130J inherits C-130J glass cockpit and avionics, including two head-up displays and computers, which represent reduced workload for aircrews and allowing crew members to spend more time on mission work. The United States National Hurricane Center gets all the weather information needed from the plane straight from the eye of the storm. Then forecasters can use the data to provide a more trustworthy hurricanes and/or storms path prediction. The WC-130J storm hunter aircraft was deployed for the first time ever on 20 May 2005 by the 53rd Weather Reconnaissance Squadron, dubbed Hurricane Hunters, based at Keesler Air Force Base, Mississippi. Hurricane Adrian appeared in the Pacific off the coast of Central America and was threatening El Salvador. The first flight mission lasted for over 11 hours.

Air & Air Defense Specifications
Crew 3
Max Speed 705.6 km/h
Range 4390.0 km
Service Ceiling 10058 m
Wingspan 39.70 m
Overview (Deagel)
Group Surveillance & Reconnaissance Airplanes
Status Active
Also Known As Hurricane Hunter (nickname), WeatherBird (nickname)
Origin United States of America
Contractor Lockheed Martin
Initial Operational Capability (IOC) 2005
Total Production 10
Specifications (Deagel)
Crew 3
Number of Engines 4
Passengers 64
Dimensions — Height 11.4 meter
Dimensions — Length 29.3 meter
Dimensions — Wingspan 39.7 meter
Mass — Max Takeoff Weight 70,308 kilogram
Mass — Payload 21,151 kilogram
Performance — Ceiling 10,058 meter
Performance — Max Range 4,390 kilometer
Power — Max Power at TakeOff 18,364 shp
Speed — Top Speed at High Altitude 196 mps
Gear (Deagel)
Item 1 ESM & Warning Systems: AN/ALR-56
Item 2 Radar Systems: AN/APN-241 (1)
Item 3 Turboprop Engines: AE 2100D3 (4)
Variants
Variant 1 C-130H Hercules
Variant 2 MC-130H Talon II
Variant 3 AC-130U Spooky
Variant 4 C-130J Super Hercules
Variant 5 CC-130J Super Hercules
Variant 6 KC-130J Super Hercules
Variant 7 WC-130J
Variant 8 MC-130W Combat Spear
Variant 9 EC-130J Commando Solo
Variant 10 MC-130J Commando II
Variant 11 AC-130J Ghostrider
Variant 12 LM-100J
Variant 13 C-130J-SOF
Details
Country of Origin United States
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
29.3 m
Width
39.7 m
Height
11.4 m
Weight
70308 kg
Operators (1)
United States
