ZQHW-350E Chinese Unmanned Aerial Vehicle (UAV)
ZQHW-350E
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
ZQHW-350E Chinese Unmanned Aerial Vehicle (UAV)
Designation
ZQHW-350E
Alternate Designation
ZQHW-350E
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
China Defense Equipment Co
Date of Introduction
2024
Description
The ZQHW-350E Chinese Unmanned Aerial Vehicle (UAV) adopts high-performance aerodynamic shape design and composite fuselage.It has the characteristics of long endurance, wide range of use and rich load types.It can carry optical pod, communication equipment, navigation equipment, small synthetic aperture radar etc.It can be widely used in many fields such as sea area monitoring, meteorological detection, test with flight, emergency communication and rescue, etc.
Air & Air Defense Specifications
Engine
Gasoline
Max Speed
180.0 km/h
Cruise Speed
130.0 km/h
Range
100.0 km
Endurance
18.00 hrs
Service Ceiling
4500 m
Wingspan
8.50 m
Payload Capacity
30 kg
System
Alternate Designation
ZQHW-350E
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
China Defense Equipment Co.
Payload Capacity
30-50 kg
Control Distance
100 km
Takeoff and Landing
Fully autonomous wheel
Takeoff Preparation Time
30 min
System Strorage Temperature
-40℃~+55℃
Working Temperature of Airborne Equipment
-40℃~+55℃
Working Temperature of Ground Equipment
-40℃~+55℃
Dimensions
Length
5.8 m
Height
1.6 m
Wingspan
8.5 m
Maximum Takeoff Weight
240 kg
Automotive
Engine Name
INA
Engine Type
Gasoline
Engine Power
INA
Maximum Speed
180 km/h
Cruise Speed
130 km/h - 150 km/h
Maximum Range
100 km
Wind Resistance
15m/s
Service Ceiling
4,500 m
Endurance
18h (payload 20kg)
Image Sources
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
Z
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
5.8 m
Width
8.5 m
Height
1.6 m
Weight
240 kg
Operators (1)
China
