PSNR-8 Kredo-M1 Russian Portable Ground Surveillance Radar System
PSNR-8 Kredo-M1
Portable Ground Surveillance Radar System
Other
Basic Information
Name
PSNR-8 Kredo-M1 Russian Portable Ground Surveillance Radar System
Designation
PSNR-8 Kredo-M1
Alternate Designation
PSNR-8 Kredo-M1
Equipment Type
Portable Ground Surveillance Radar System
Manufacturer
—
Date of Introduction
2002
Description
The PSNR-8 Kredo-M1 portable ground surveillance radar system was adopted by the Russian Armed Forces only in 2002. The PSNR-8 Kredo-M1 portable ground surveillance radar system is designed to detect moving targets on the ground or water and to support artillery fire at any time of the day regardless of the season, and also in conditions of low visibility (fog, rain, snow, dust, or smoke)
Ground Specifications
Crew
2
System
Alternative Designation
PSNR-8 Kredo-M1
Type
Portable Ground Surveillance Radar System
In Service
2002-Present
Family
INA
Crew
2-3 ea
Operating Frequency Range
2 cm (J)
Range, Scan Zone
200 meters to 32 km
Azimuth, Scan Zone
from 12° to 180° with an adjustment discrete of 12°
Maximum Elevation, Scan Zone
+18 deg
Minimum Elevation, Scan Zone
-18 deg
Detection Range, Person
7-8 km
Detection Range, Tank
16 km
Detection Range, Truck
32 km
Detection Range, 155mm Shell Explosion
5 km
Power Consumption
110 w
Continuous Operating Time
24 hours
Median Errors in Determining the Coordinates for Range
25 m
Median Errors in Determining the coordinates for Direction
00–05 m (0.3°)
Dimensions
Length
INA
Width
INA
Height
INA
Weight, Combat
51 kg
Details
Country of Origin
Russia
Category
Radars
Land > Radars
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
51 kg
Operators (1)
Russia
