HT-750 Swiss Unmanned Aerial Vehicle (UAV)
HT-750
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
HT-750 Swiss Unmanned Aerial Vehicle (UAV)
Designation
HT-750
Alternate Designation
HT-750
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Anavia
Date of Introduction
2025
Description
The HT-750 Swiss Unmanned Aerial Vehicle (UAV) stands as the world’s leading heavy-lift unmanned VTOL system – ready for every mission, in every deployment. The lightweight, carbon-structured HT-750 is capable of performing a variety of missions typically conducted by conventional helicopters, including transport and reconnaissance. The manufacturer also lists several potential tasks, such as aerial infrastructure inspection, traffic surveillance, crime and narcotics-smuggling investigation, border and coastal patrol, fire prevention, as well as combating illegal fishing and poaching.
Air & Air Defense Specifications
Engine
Turboshaft
Max Speed
222.0 km/h
Range
200.0 km
Endurance
15.00 hrs
Service Ceiling
4000 m
Rotor Diameter
7.50 m
System
Alternate Designation
HT-750
Type
Unmanned Aerial Vehicle (UAV
Manufacturer
Anavia
Payload Capacity with Fuel
750 kg
Data Link Type
Fully encrypted MESH IP (limitless SATCOM, dual MIMO radios with up to 100 Mbps data rate and AES256 encryption)
Data Link Range
Dependent on terrain topography and national regulations – radio
and antenna configuration up to 200 km
Operating Temperature
-25 °C to +55 °C
Start and Landing
Fully autonomous
Dimensions
Length
6.88 m
Width
1.67 m
Height
3.35 m
Rotor Diameter
7.50 m
Empty Weight
400 kg
Maximum Takeoff Weight
1,150 kg
Automotive
Engine Name
INA
Engine Type
Gas turbo-shaft engine
Engine Power
INA
Rotor
Semi-rigid 4-blade bearing-less rotor system
Tank Capacity
900 liters
Fuel Types
Jet A1 – other fuel types on demand (JP-8, JP-5)
Fuel Consumption
60 l/h
Maximum Speed
222 km/h
Maximum Range
200 km
Service Ceiling
4,000 m
Endurance
15 hours
Max Wind Speed
45 km/h
Max. Flight Mission/ Payload Weight
1 hrs/51 kg;
2 hrs/43 kg;
4 hrs/28 kg;
6 hrs/14 kg
Details
Country of Origin
Switzerland
Category
UAVs
Air > UAVs
Filter Label
H
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
6.88 m
Width
1.67 m
Height
3.35 m
Weight
1150 kg
Operators (2)
Switzerland
United Arab Emirates
