Pantsir-S2 Russian 8x8 Self-Propelled Anti-Aircraft System
Pantsir-S2
Self-Propelled Anti-Aircraft Gun (SPAAG)
Other
Basic Information
Name
Pantsir-S2 Russian 8x8 Self-Propelled Anti-Aircraft System
Designation
Pantsir-S2
Alternate Designation
Pantsir-S2
Equipment Type
Self-Propelled Anti-Aircraft Gun (SPAAG)
Manufacturer
Ulyanovsk Mechanical Plant
Date of Introduction
2015
Description
The Pantsir-S2 Russian 8x8 Self-Propelled Anti-Aircraft Weapon System is an improved version of the Pantsir-S1 which uses the same missile launcher and anti-aircraft cannons.
Ground Specifications
Crew
3
Mobility Type
Wheeled (8x8)
Main Weapon
2 x 2A38M 30mm Anti-Aircraft Guns
Engine
Diesel (400 hp)
Max Speed
90.0 km/h
Range
800.0 km
Variants
Pantsir-S1
This is the first and most numerously produced variant, being produced from 2008 to 2013, with more planned in 2019.
Pantsir-S1M
New upgraded variant of the Pantsir-S1 first unveiled in February 2019 as some of the planned models.
Pantsir-M/EM
A naval variant of the land-based Pantsir-S1 was unveiled in July 2015.
Pantsir-SM
The Pantsir-SM variant incorporates a multi-functional targeting station, increasing target detection range from 40 to 75 km (25 to 47 mi) and engagement range from 20 to 40 km (12 to 25 mi).
Pantsir-SA
After testing Pantsir in the Arctic, it was decided to design a new variant specifically for the Arctic, to use at temperatures below −50 °C (−58 °F) called the Pantsir-SA.
Pantsir-SMD-E
Russia has announced a new variant of its Pantsir short-range air defense system that can be loaded with as many as 48 small interceptors and that it says is specifically intended to help shield critical infrastructure from uncrewed aerial threats. The new SMD-E variant of Pantsir has a turret that can be loaded with up to 12 57E6-series short-range command-guided surface-to-air missiles, as many as 48 TKB-1055 very-short-range interceptors, or a mix thereof. The TKB-1055 is a relatively recent development focused heavily on defeating drone threats and has a stated maximum range of just over 4 miles (7 kilometers) compared to the 57E6-E’s nearly 12 and a half miles (20 kilometers), per a placard seen at Army 2024. Like previous versions of Pantsir, the SMD-E’s turret also has two integrated radars, one for spotting and tracking targets and another fire control type for directing the command-guided missiles.
System
Alternative Designation
Pantsir-S2
Type
Self-Propelled Anti-Aircraft System
Manufacturer
Ulyanovsk Mechanical Plant
Configuration
8x8
Chassis
KAMAZ 656
Crew
3 ea
Dimensions
Length
10.3 m
Width
2.5 m
Height
3.27 m
Wheelbase
3.6 m
Weight, Combat
14,850 kg
Automotive
Engine Name
YaMZ-5367
Engine Type
Diesel
Engine Power
400 hp
Maximum Range
800 km
Maximum Speed
90 km/h
Amphibious
No
Gradient
60%
Side Slope
40%
Vertical Step
0.6 m
Trench
2.0 m
Fording
1.8 m
Gun Weapon System
System
Name
2 x 2A38M 30mm Anti-Aircraft Guns
Type
Anti-Aircraft Guns
Caliber
30 mm
Length
INA
Barrel Length
INA
Weight
195 kg gun only
Action
Gas Operated
Rate of Fire
INA
Burst Length
83 - 250 rounds
Muzzle Velocity
960 - 980 m/s
Maximum Firing Range
200 to 2,000 m in altitude with a maximum slant range of 4,000 m.
Cooling System
Water cooled
Feed System
Belt fed, single belt feed
Ammunition
Type
Rifle
Caliber
30 mm
Cartridge
30x165mm
Basic Load
INA
Missile Weapon System
Name
12 x 57E6-E Surface-to-Air Missiles
Type
Surface-to-Air Missiles
Length
INA
Missile Weight
74.5 kg
Warhead Type
INA
Warhead Weight
20
Number of Stages
2 ea
Minimum Range
1,200 m
Maximum Range
20,000 m
Target Maximum Altitude
10,000 m
Target Maximum Speed
1,000 mps
Radar System
Name
1 x SOT Target and Fire Control Radar
Type
Target and Fire Control Radar
Band
S-Band
Number of Targets
40 ea
Search Azimuth
90°
Coverage
360° coverage
Maximum Detection Range
40 km
Maximum Engagement Speed
1,200 mps
Note
The shape of the new antenna has change and is mounted at the top of the turret.
Protection
Armor
None
Turret Armor
INA
Applique Armor
No
NBC Protection
INA
Smoke Equipment
No
Details
Country of Origin
Russia
Category
Land
Land
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
10.3 m
Width
2.5 m
Height
3.27 m
Weight
14850 kg
Operators (13)
Russia
Ukraine
Iran
Serbia
Algeria
Equatorial Guinea
Ethiopia
Jordan
Myanmar
Oman
Syria
United Arab Emirates
Vietnam
