MiG-19 (Farmer) Russian Fighter Aircraft
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
MiG-19 (Farmer) Russian Fighter Aircraft
Designation
—
Alternate Designation
—
Equipment Type
—
Manufacturer
Mikoyan
Date of Introduction
1955
Description
The Mikoyan-Gurevich MiG-19 (Russian: Микоян и Гуревич МиГ-19; NATO reporting name: Farmer) is a Soviet second-generation, single-seat, twin jet-engined fighter aircraft, the world's first mass-produced supersonic aircraft. It was the first Soviet production aircraft capable of supersonic speeds in level flight. A comparable U.S. "Century Series" fighter was the North American F-100 Super Sabre, although the MiG-19 would primarily oppose the more modern McDonnell Douglas F-4 Phantom II and Republic F-105 Thunderchief over North Vietnam.
Air & Air Defense Specifications
Crew
1
Engine
Turbojet
Cruise Speed
950.0 km/h
Wingspan
9.20 m
Variants
Farmer-A
Initial production day fighter version with Klimov VK-5 engine, one 37-mm and two 23-mm cannon, plus wing pylons for rocket pods.
Farmer-B (MiG-19S)
Similar to Farmer-A, but with Klimov RD-9B engine, night/all-weather capability.
Farmer-C
Day fighter version with new armament. Models with AM-5 engine designated MiG-19S; those with RD-9F engine designated MiG-19SF.
Farmer-D
Similar to Farmer-C, but with all-weather capability. Models with Farmer-C armament are designated MiG-19PF; those carrying four AA-1 Alkali** missiles are designated MiG-19PM.
Farmer-E
Day fighter version with same armament as the MiG-19PM.
J-6/F-6
Chinese-manufactured versions; see separate database entry.
System
Alternate Designation(s)
MiG-19; NATO: Farmer
Primary Function / Type
Fighter Aircraft
Manufacturer
Mikoyan-Gurevich
Crew
1 ea
Number of Engines
2 ea
Number of Hard Points
4 pylons in total, 2 for drop fuel tanks only, 2 for weapons, with a capacity of up to 500 kg (1,100 lb) of stores
Dimensions
Length
12.54 m
Height
3.80 m
Wingspan
9.20 m
Wing Area
25.0 sq m
Weight, Empty
5,500 kg
Weight, Normal Takeoff
7,500 kg
Weight, Maximum Takeoff
10,200 kg
Automotive
Engine Name
2 x Klimov RD-9F
Number of Engines
2 ea
Engine Type
Turbojet
Engine Power, Dry
2,800 kg static thrust each
Engine Power, with Afterburner
3,568 kg static thrust each
Internal Fuel Capacity
2,170 liters
Maximum Speed, High Altitude
1,452 km/h, Mach 1.35
Maximum Speed, Sea Level
1,339 km/h, Mach 1.1
Cruise Speed
950 km/h, Mach 0.9
Climb Rate
6,900 m/min
Ceiling
16,775 m
Ferry Range
2,200 km
Main Gun System
System
Name
Nudelman-Rikhter NR-30
Type
Autocannon
Caliber
30 mm
Quantity
3 × 30 mm Nudelman-Rikhter NR-30 autocannon
Length
2,153 mm
Barrel Length
1,600 mm
Width
181 mm
Height
186 mm
Weight
66 kg
Barrels
1 ea
Action
Short recoil
Rate of Fire
850–1,000 rpm
Muzzle Velocity
780 m/s
Ammunition
Type
Rifle
Caliber
30 mm
Cartridge
30x155mm
Basic Load
(75 rounds for wing-root guns, 55 rounds for the fuselage gun
Main Missile Systems
Main Missile System #1
Name
K-13; NATO: AA-2 Atoll
Type
Infrared Homing Air-to-Air Missile
Length
2.830 m
Diameter
127 mm
Wingspan
631 mm
Weight
90 kg
Warhead Weight
7.4 kg
Operational Range
1-3.5 km
Maximum Speed
Mach 2.5
Guidance System
infrared homing
Fire Control / Avionics
Fire Control System Type
INA
Fire Control Radar
INA
Laser Desingator
INA
Protection
Stealth Properties
No
Heat Signature Reduction
No
Add on Armor
INA
NBC Protection
INA
EW Counter Measures
INA
Chaffs/Flares
INA
Details
Country of Origin
Russia
Category
Fixed Wing Aircraft
Air > Fixed Wing Aircraft
Filter Label
M
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
12.54 m
Width
—
Height
3.8 m
Weight
7500 kg
Operators (11)
China
Poland
North Korea
Pakistan
Afghanistan
Bulgaria
Cuba
Hungary
Indonesia
Iraq
Romania
