V-247 Vigilant

V-247 Vigilant

Reconnaissance & Strike Drones
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
V-247 Vigilant
Designation
V-247 Vigilant
Alternate Designation
Equipment Type
Reconnaissance & Strike Drones
Manufacturer
Bell Textron
Date of Introduction
2023
Description

The Bell V-247 Vigilant is an unmanned tilt-rotor aircraft combining the flexibility of a rotary-wing aircraft and the speed and range of a fixed-wing airplane. The V-247 has been designed to meet the requirements of the US Marine Corps for Group 5 UAS long-endurance persistent expeditionary and surveillance capability with the option to employ lethal weapons. Besides, mission packages will allow to perform electronic warfare (EW); intelligence, surveillance and reconnaissance (ISR); escort; C4 (Command, Control, Communications and Computer); fire support and tactical distribution missions. This unmanned aerial system (UAS) can operate from both a wide range of maritime platforms and unprepared ground runways. Bell unveiled the new aircraft in September 2016 and expects to start serial production of the V-247 as soon as 2023. The V-247 Vigilant is powered by a single engine achieving a top speed of 300 knots (+500 kilometers per hour) while staying airborne for 11 hours. The two rotors are mounted on folded wings to fit into hangar of destroyer-sized ships. The two internal bays can carry a wide range of sensor packages as well as weapons such as an Mk-50 torpedo or Hellfire and JAGM missiles.

Air & Air Defense Specifications
Max Speed 555.6 km/h
Range 5185.6 km
Service Ceiling 7620 m
Wingspan 19.81 m
Overview (Deagel)
Group Reconnaissance & Strike Drones
Status Under Development
Origin United States of America
Contractor Bell Textron
Initial Operational Capability (IOC) 2023
Total Production ?
Specifications (Deagel)
Crew 0
Main Rotor Blades 6
Number of Engines 1
Dimensions — Main Rotor Diameter 30 foot
Dimensions — Wingspan 65 foot
Mass — Empty Weight 16,000 pound
Mass — Fuel Load 11,000 pound
Mass — Max Takeoff Weight 29,500 pound
Mass — Payload 2,000 pound
Performance — Ceiling 25,000 foot
Performance — Max Range 2,800 nautical mile
Performance — Radius of Operation 450 nautical mile
Speed — Cruise Speed 240 knot
Speed — Loiter Speed 178 knot
Speed — Top Speed at High Altitude 300 knot
Time — Flight Endurance 11 hour
Gear (Deagel)
Item 1 Anti-Tank Guided Missiles: AGM-114R Hellfire II (4)
Item 2 Anti-Tank Guided Missiles: AGM-179A JAGM (4)
Item 3 Torpedoes: Mark 50 (2)
Details
Country of Origin United States
Category UAVs
Air > UAVs
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
19.81 m
Height
Weight
13380.96 kg
Operators (1)
United States
