Basic Information
Name
F123 Upgraded
Designation
F123 Upgraded
Alternate Designation
—
Equipment Type
Frigates
Manufacturer
Saab, Abeking & Rasmussen, ESG Elektroniksystem-und Logistik-GmbH
Date of Introduction
2027
Description
In July 2021 the German Ministry of Defense selected Saab to upgrade the F123 class frigates incorporating new radar systems and fire control systems. The upgrade is planned to be completed between 2021 and 2030. The frigates will be provided with the Sea Giraffe 4A and Sea Giraffe 1X radars as well as 9LV combat management system and CEROS 200 fire control director. The Saab team includes Abeking & Rasmussen shipyard and ESG.
Naval & Littoral Specifications
Crew
230
Displacement
4700.00 tonnes
Beam
16.70 m
Draft
4.40 m
Max Speed
30.0 knots
Overview (Deagel)
Group
Frigates
Status
Under Development
Origin
Germany
Contractors
Saab*, Abeking & Rasmussen, ESG Elektroniksystem-und Logistik-GmbH
Initial Operational Capability (IOC)
2027
Total Production
?
Specifications (Deagel)
Crew
230
Number of Weapons
20
Dimensions — Beam
16.7 meter
Dimensions — Draft
4.4 meter
Dimensions — Length
139 meter
Dimensions — Main Gun Caliber
76 millimeter
Mass — Full Displacement
4,700 ton
Performance — Max Range
6,500 kilometer
Power — Total Combined Power
50,000 shp
Speed — Cruise Speed
18 knot
Speed — Top Speed
30 knot
Gear (Deagel)
Item 1
Anti-Ship Missiles: MM38 Exocet (4)
Item 2
ASW Helicopters: Super Lynx (2)
Item 3
Combat Management Systems: 9LV (1)
Item 4
Combat Management Systems: CEROS 200 FCS (1)
Item 5
Decoy Systems: MASS
Item 6
Naval Gun Systems: 76/62 Compact (1)
Item 7
Radar Systems: Sea Giraffe 1X (1)
Item 8
Radar Systems: Sea Giraffe 4A (1)
Item 9
Sea-Based Air Defense Systems: Mk-31 RAM
Item 10
Ship Power Plants: LM2500 (2)
Item 11
Surface-to-Air Missiles: RIM-116A/B RAM
Item 12
Surface-to-Air Missiles: RIM-7M SeaSparrow (16)
Variants
Variant 1
F123 Brandenburg
Variant 2
F123 Upgraded
Details
Country of Origin
Germany
Category
Frigates
Naval > Frigates
Sources
deagel.com: https://www.deagel.com/x/x/a000441
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
139 m
Width
16.7 m
Height
—
Weight
4700000 kg
Related Equipment (1)
Variant of
Operators (1)
Germany
