Laska Ukrainian 4x4 Unmanned Ground Vehicles (UGV)
Laska
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Laska Ukrainian 4x4 Unmanned Ground Vehicles (UGV)
Designation
Laska
Alternate Designation
Laska
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Infocom
Date of Introduction
2015
Description
The Laska Ukrainian 4x4 Unmanned Ground Vehicles (UGV) were developed to be used with the land forces of the armed forces.
Ground Specifications
Mobility Type
Wheeled (4x4)
Engine
1 cylinder (4 tact) (10 hp)
Range
200.0 km
System
Alternative Designation
Laska
Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Infocom
Configuration
4x4
Crew
Unmanned
Operator
Control of the unit can be carried out by various means such as an operator station, tablet, smartphone, or quadrocopter. The platform can operate for distances of up to 200 km with repeaters.
Sensors
A range of systems are available to offer the operator full situational awareness such as a variety of wide-angle, long- and short-range cameras (and those with IR) mounted to the turret and platform. Stereo cameras and radar can also be fitted if required.
Software
Laska can operate autonomously in a driving convoy (following a lead vehicle) or by GPS for waypoint navigation. It can also operate without GPS in environmentally cluttered areas or those with GPS-denial by using a downloaded digital area map as well as sensors and video cameras to analyze the vicinity.
Camera
Various cameras (wide angle, stereo, IR), optical and laser sensors (ultrasonic distance sensor) are fitted to the vehicle.
Camera, Angle of View
12–20°
Operating Temperature
-25°C to 60°C
Dimensions
Length
1.8 m
Width
1.0 m
Height
1.3 m
Wheelbase
120 cm
Weight, Combat
310 kg
Ground Clearance
13.6 cm
Automotive
Engine Name
INA
Engine Type
1 cylinder (4 tact)
Engine Power
10 hp
Voltage
12 V
Amphibious
No
Maximum Speed
INA
Operating Range, Line of Sight (LoS)
100 m
Operating Range, No Line of Sight (NLoS)
100 m
Communications
Note
A number of communication methods can be used such as Wi-Fi, Ethernet VPN channel, radio channel, loud speaker system, 3G networks, and a special security channel.
Main Weapon System
Note
INA
Protection
Armor
Light composite (Level 5 optional)
Applique Armor
INA
Details
Country of Origin
Ukraine
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
L
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.8 m
Width
1 m
Height
1.3 m
Weight
310 kg
Operators (1)
Ukraine
