UR-15 Meteor Russian Tracked Demining Unmanned Ground Vehicle (UGV)
UR-15 Meteor
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
UR-15 Meteor Russian Tracked Demining Unmanned Ground Vehicle (UGV)
Designation
UR-15 Meteor
Alternate Designation
UR-15 Meteor
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Rosoboronexport
Date of Introduction
2018
Description
The UR-15 Meteor Tracked Demining Unmanned Ground Vehicle (UGV) is designed to clear lanes through minefields by means of a line charge. A base vehicle is used to carry the launcher and five mine-clearing line charges, which use jet engines to fly over the minefield.
Ground Specifications
Mobility Type
Tracked
Main Weapon
7.62×54 mm PKT machine gun
Engine
The platform features a new hybrid electric drive system.
Max Speed
60.0 km/h
System
Alternative Designation
UR-15 Meteor
Type
Demining Unmanned Ground Vehicle (UGV)
Manufacturer
ROSOBORONEXPORT Federal State Unitary Enterprise
Configuration
Tracked
Crew
Unmanned
Operator
INA
Dimensions
Length
7.14 m
Width
3.23 m
Height
2.02 m
Weight, Combat
22 tons
Automotive
Engine Name
INA
Engine Type
The platform features a new hybrid electric drive system.
Engine Power
INA
Maximum Land Speed
60 km/h
Maximum Amphibious Speed
5 km/h
Operating Range
On batteries the vehicle can travel a distance up to 3 km.
Batteries
Batteries enable driving in silent mode and without the use of the diesel engine.
Main Weapon System
Note
A remote-controlled weapon station is located on the roof of the hull (above the control compartment) and can be equipped with a 7.62×54 mm PKT machine gun.
Mine Clearing Equipment
Launch Tubes
Launch tubes feature on the upper frontal part and on the roof of the hull, which are likely for the Afghanit active protection system (APS).
Type of Line Charge
Razrez
Charge Range
>500 m
Length of Line Charge
>93 m
Protection
Armor
The UR-15 Meteor retains its aluminum-steel armored body to protect against small-caliber artillery from the front angles.
Applique Armor
Additional protection is offered, on the lower frontal plate, there are two electromagnetic attachments for protection against mines with magnetic target sensors.
Active Protection
Afghanit active protection system (APS)
Smoke
On the sides of the hull at the top, on the sides of the launcher, there are two blocks of six smoke grenade launchers.
Details
Country of Origin
Russia
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
U
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.14 m
Width
3.23 m
Height
2.02 m
Weight
22000 kg
Operators (1)
Russia
