VLRA 2

VLRA 2

Military Trucks
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
VLRA 2
Designation
VLRA 2
Alternate Designation
Equipment Type
Military Trucks
Manufacturer
ACMAT
Date of Introduction
2010
Description

The VLRA (Vehicule de Liaison de Reconnaissance et d'Appui / Liaison, Reconnaissance and Support Vehicle) 4x4 is a family of all wheel drive military trucks developed by ACMAT and capable of carrying payloads ranging from 1.5-ton to 3.5-ton. The VLRA 2 is a follow-on development based upon a 4x4 chassis capable of carrying a payload between 2 and 4.5 tons or up 17 persons. Compared with the VLRA1, the new vehicle is heavier, has a larger cargo capacity and provides a greater range thanks to its Euro 5 190-hp turbo diesel intercooler engine. ACMAT has developed a 15-ton class Mine Resistant Ambush Protected (MRAP) vehicle based on the VLRA 2 chassis. The VLRA 2 4x4 is a multipurpose tactical vehicle that carry a load of 4.5-ton over ranges of up to 1,400 km using two fuel tanks (2 x 180-l). The vehicle's cab accommodates a three-man crew with seating for up to 14 passengers in the rear compartment. It can be equipped with small caliber weapons such as 12.7mm and 7.62mm machine guns or a 40mm automatic grenade launcher as well as anti-tank and anti-air missile systems. The VLRA 2 vehicle can be airlifted by tactical transport aircraft such as the C-130, C-160 and A400M as well as CH-47 helicopters.

Ground Specifications
Crew 3
Troop Capacity 14
Mobility Type Wheeled (4x4)
Max Speed 110.0 km/h
Range 1400.0 km
Overview (Deagel)
Group Military Trucks
Status Active
Origin France
Contractor ACMAT
Initial Operational Capability (IOC) 2010
Total Production ?
Specifications (Deagel)
Crew 3
Troops 14
Wheel Drive 4
Wheels 4
Degree — Approach Angle 46 °
Degree — Departure Angle 45 °
Dimensions — Ground Clearance 0.35 meter
Dimensions — Height 2.4 meter
Dimensions — Length 7.2 meter
Dimensions — Track 1.8 meter
Dimensions — Wheelbase 4.8 meter
Dimensions — Width 2.4 meter
Energy — Max Torque 680 Nm
Mass — Cargo 4,500 kilogram
Mass — Max Weight 15,000 kilogram
Mass — Operational Weight 10,500 kilogram
Percentage — Gradient 65 %
Percentage — Side Slope 30 %
Performance — Ditch Crossing Ability 0.80 meter
Performance — Fording Depth 1 meter
Performance — Max Range 1,400 kilometer
Performance — Step Climbing Ability 0.50 meter
Performance — Turning Radius 14.5 meter
Power — Power 190 hp
Speed — Top Speed 110 kph
Volume — Fuel Tank Capacity 360 liter
Variants
Variant 1 VLRA 4x4
Variant 2 VLRA 6x6
Variant 3 VLRA 2
Details
Country of Origin France
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.2 m
Width
2.4 m
Height
2.4 m
Weight
15000 kg
Operators (1)
France
