Kamaz-65224

Kamaz-65224

Military Trucks
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Kamaz-65224
Designation
Kamaz-65224
Alternate Designation
Equipment Type
Military Trucks
Manufacturer
Kamaz
Date of Introduction
Description

The Kamaz-65224 is a 26-ton class, 6x6 flexible and mobile multipurpose truck system intended to carry personnel and cargo as part of the logistics support for military and peacekeeping missions. It is also suitable for other applications such as water/fuel tank bodies carrier, loading cranes, special purpose vans, and various weapon systems platform. This truck can tow trailers and keep on moving through desert sands and along stony tracks, over scree and mud, snow and ice thanks to its all-wheel drive climbing the most extreme gradients, ford rivers and chase across any terrain. It is powered by a Kamaz 750.50 Euro 2 turbocharged diesel V8 engine developing 347-hp of power and a maximum torque of 1,450 Nm. Kamaz created three classes of multipurpose vehicles with 6-ton, 8-ton and 10-ton axial load developing a full range of 4x4, 6x6, 8x8 military trucks sharing 85 percent of components and designed to meet military requirements. The trucks have the option of an armored cab including hidden armoring of the cab. The Kamaz-65224 truck is able to carry up to 14-ton payload and towing a trailer of 12-ton. Kamaz has produced this truck system for the Russian Ministry of Defense and export customers across the world.

Ground Specifications
Mobility Type Wheeled (6x6)
Overview (Deagel)
Group Military Trucks
Status Active
Origin Russia
Contractor Kamaz
Total Production ?
Specifications (Deagel)
Wheel Drive 6
Wheels 6
Dimensions — Length 6.1 meter
Dimensions — Wheelbase 4.2 meter
Dimensions — Width 2.5 meter
Energy — Max Torque 1,450 Nm
Mass — Cargo 14,000 kilogram
Mass — Max Gross Train Weight 38,350 kilogram
Mass — Max Weight 26,350 kilogram
Mass — Towed Load 12,000 kilogram
Percentage — Gradient 60 %
Performance — Ditch Crossing Ability 0.60 meter
Performance — Fording Depth 1.8 meter
Performance — Step Climbing Ability 0.55 meter
Power — Power 347 hp
Details
Country of Origin Russia
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.1 m
Width
2.5 m
Height
Weight
38350 kg
Operators (1)
Russia
