BMK-225 Russian Bridging Boat
BMK-225
Combat Rubber Raiding Craft (CRRC)
Other
Basic Information
Name
BMK-225 Russian Bridging Boat
Designation
BMK-225
Alternate Designation
BMK-225; Towing Motorboat Projects 14120, 14121, and 14122
Equipment Type
Combat Rubber Raiding Craft (CRRC)
Manufacturer
The BMK-225 is understood to have been developed by a member (or members) of the Medium and Small Tonnage Shipbuilding (KSMK) Joint Stock Company (JSC), and is marketed by Vympel Shipyard JSC. KSMK comprises Yantar Shipyard (Kaliningrad), Vympel Shipyard JSC (Rybinsk), JSC Interregional Investment Bank (MIB) (Moscow), Amur Shipyard (Komsomolsk-on-Amur), Kazan Electrotechnikal Plant JSC (Kazan), and Khabarovsk Shipbuilding Plant (Khabarovsk). Some sources have suggested that the boat is also manufactured by JSC Kostroma Wharf.
Date of Introduction
2011
Description
The BMK-225 Russian Bridging Boat is also known as Towing Motorboat Projects 14120, 14121, and 14122. The BMK-225 was designed for use with the PP-91 pontoon equipment set, with an allocation of four boats per set. The BMK-225 has been seen as a possible long-term replacement for earlier-generation bridging boats in service with the Russian army and potentially others using Russian-supplied bridging equipment.
Ground Specifications
Crew
2
Engine
Diesel (225 hp)
Max Speed
17.0 km/h
Range
170.0 km
System
Alternative Designation
BMK-225; Towing Motorboat Projects 14120, 14121, and 14122
Type
Bridging Boat (A)
Manufacturer
The BMK-225 is understood to have been developed by a member (or members) of the Medium and Small Tonnage Shipbuilding (KSMK) Joint Stock Company (JSC), and is marketed by Vympel Shipyard JSC. KSMK comprises Yantar Shipyard (Kaliningrad), Vympel Shipyard JSC (Rybinsk), JSC Interregional Investment Bank (MIB) (Moscow), Amur Shipyard (Komsomolsk-on-Amur), Kazan Electrotechnikal Plant JSC (Kazan), and Khabarovsk Shipbuilding Plant (Khabarovsk). Some sources have suggested that the boat is also manufactured by JSC Kostroma Wharf.
Crew
2 ea
Dimensions
Length
9.06 m
Beam
2.76 m
Height
INA
Draft
650 mm (at full load); 590 mm at light load
Weight
7,450 kg
Automotive
Engine Name
SMD-601
Engine Type
Diesel
Engine Power
225 hp
Maximum Range
170 km (cruising); 10 hours continuous working
Maximum Speed
17 km/h
Foward Thrust
1,800 kg
Reverse Thrust
1,000 kg
Operational Limits
3 m/s flow rate
Protection
Armor
None
Applique Armor
No
NBC Protection
No
Smoke Equipment
No
Image Sources
Details
Country of Origin
Russia
Category
Mobility
Land > Combat Support Vehicles > Mobility
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
9.06 m
Width
2.76 m
Height
—
Weight
7450 kg
Operators (1)
Russia
