EC-130J Commando Solo

EC-130J Commando Solo

Communications Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
EC-130J Commando Solo
Designation
EC-130J Commando Solo
Alternate Designation
EC-130SJ Super J
Equipment Type
Communications Aircrafts
Manufacturer
Lockheed Martin
Date of Introduction
2007
Description

The first C-130J aircraft achieved initial operational capability in 1999. The US Air Force plans to purchase up to 168 C-130J and CC-130J (a stretch version of C-130J) aircraft to replace older C-130Es. In November 2004, the US Air Force awarded Lockheed-Martin a contract to turn 1+2 Air National Guard C-130Js into Super J aircraft configuration. Super J configuration features aerial refueling equipment, a modified operator station, an expanded internal communications system, plus a more powerful generator for needed electrical power. It is expected that the first Super J configured aircraft, to be sent back to the Air National Guard in 2006, will be ultimately converted into the first EC-130J aircraft. EC-130Js would replace the existing fleet of aging EC-130E Commando Solo aircraft beginning before the end of this decade (2010). EC-130Js will perform information operations and civil affairs broadcasts in AM, FM, HF, TV and military communications bands.

Air & Air Defense Specifications
Crew 3
Max Speed 705.6 km/h
Range 4390.0 km
Service Ceiling 10058 m
Wingspan 39.70 m
Overview (Deagel)
Group Communications Aircrafts
Status Active
Also Known As EC-130SJ Super J
Origin United States of America
Contractor Lockheed Martin
Initial Operational Capability (IOC) 2007
Total Production 7
Unitary Cost USD $110 million
Specifications (Deagel)
Crew 3
Number of Engines 4
Passengers 64
Dimensions — Height 11.4 meter
Dimensions — Length 29.3 meter
Dimensions — Wingspan 39.7 meter
Mass — Max Takeoff Weight 70,308 kilogram
Mass — Payload 21,151 kilogram
Performance — Ceiling 10,058 meter
Performance — Max Range 4,390 kilometer
Power — Max Power at TakeOff 18,364 shp
Speed — Top Speed at High Altitude 196 mps
Gear (Deagel)
Item 1 ESM & Warning Systems: AN/ALR-56
Item 2 ESM & Warning Systems: NexGenMWS
Item 3 Radar Systems: AN/APN-241 (1)
Item 4 Turboprop Engines: AE 2100D3 (4)
Variants
Variant 1 C-130H Hercules
Variant 2 MC-130H Talon II
Variant 3 AC-130U Spooky
Variant 4 C-130J Super Hercules
Variant 5 CC-130J Super Hercules
Variant 6 KC-130J Super Hercules
Variant 7 WC-130J
Variant 8 MC-130W Combat Spear
Variant 9 EC-130J Commando Solo
Variant 10 MC-130J Commando II
Variant 11 AC-130J Ghostrider
Variant 12 LM-100J
Variant 13 C-130J-SOF
Details
Country of Origin United States
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
29.3 m
Width
39.7 m
Height
11.4 m
Weight
70308 kg
Operators (1)
United States
