Il-96T
Il-96T
Freight Airliners
Basic Information
Name
Il-96T
Designation
Il-96T
Alternate Designation
—
Equipment Type
Freight Airliners
Manufacturer
Ilyushin Aviaton Complex
Date of Introduction
1998
Description
The Il-96T is a long-range, wide-body freighter derived from Il-96-300 airliner and featuring a stretched fuselage equipped with Pratt & Whitney engines and Rockwell Collins avionics. The aircraft maximum payload capacity is 92 tons distributed inside 32 international containers, but typically carries a 58-ton payload on routes of up to 9,700 kilometers. The Il-96T freighter is powered by four US-built PW2037 engines rated at 37,000 pounds of thrust. These engines are far more reliable and fuel efficient than Russian-built PS90A turbofans. The maiden flight was carried out on May 16, 2007. Russian type certification was awarded in March 1998 and FAA type certification in June 1999.
Air & Air Defense Specifications
Crew
2
Max Speed
982.8 km/h
Range
9700.0 km
Service Ceiling
12000 m
Wingspan
60.10 m
Overview (Deagel)
Group
Freight Airliners
Status
Active
Origin
Russia
Contractor
Ilyushin Aviaton Complex
Initial Operational Capability (IOC)
1998
First Flight
May 16, 1997
Total Production
?
Specifications (Deagel)
Crew
2
Number of Engines
4
Service Life Flight Hours
60000
Service Life Flights
20000
Area — Wing Area
350 square meter
Dimensions — Cargo Compartment Length
44.9 meter
Dimensions — Fuselage Diameter
6.1 meter
Dimensions — Height
15.7 meter
Dimensions — Length
63.9 meter
Dimensions — Wingspan
60.1 meter
Mass — Cargo
92 ton
Mass — Empty Weight
132 ton
Mass — Max Takeoff Thrust
148,000 pound
Mass — Max Takeoff Weight
270 ton
Performance — Ceiling
12,000 meter
Performance — Landing Run Distance
1,650 meter
Performance — Max Range
9,700 kilometer
Performance — Take Off Run Distance
2,500 meter
Speed — Cruise Speed
870 kph
Speed — Top Speed at High Altitude
273 mps
Time — Service Life
20 year
Volume — Fuel Tank Capacity
152,620 liter
Volume — Payload Capacity
776 metric ton
Gear (Deagel)
Item 1
Turbofan Engines: PW2037 (4)
Variants
Variant 1
Il-96-300
Variant 2
Il-96M
Variant 3
Il-96T
Variant 4
Il-96-400
Variant 5
Il-96-400T
Variant 6
Il-96-400M
Variant 7
Il-96-400TZ
Details
Country of Origin
Russia
Sources
deagel.com: https://www.deagel.com/x/x/a000195
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
63.9 m
Width
60.1 m
Height
15.7 m
Weight
270000 kg
Operators (1)
Russia
