JAS 39D Gripen
JAS 39D Gripen
Multi-Role Fighters
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
JAS 39D Gripen
Designation
JAS 39D Gripen
Alternate Designation
Gripen D, JAS 39B Gripen
Equipment Type
Multi-Role Fighters
Manufacturer
Saab
Date of Introduction
1998
Description
The two-seat JAS 39B Gripen was introduced in 1998 to provide training on the Gripen aircraft. It retains single-seat JAS 39 Gripen fully combat functionality. The JAS 39D is a twin-seat fighter aircraft featuring the same functionality of more capable single-seat JAS 39C Gripen. On 30 March 2006 Saab handed over the first five Gripen aircraft (3C + 2D) from a lease and purchase agreement on 12 single-seat Gripen C and 2 dual-seat Gripen D to the Hungarian Air Force at the Kecskémet air base. The remaining nine Gripen C single-seat aircraft were expected to be delivered progressively until December 2007.
Air & Air Defense Specifications
Crew
2
Max Speed
2469.6 km/h
Range
800.0 km
Service Ceiling
15240 m
Wingspan
8.40 m
Overview (Deagel)
Group
Multi-Role Fighters
Status
Active
Also Known As
Gripen D, JAS 39B Gripen
Origin
Sweden
Contractor
Saab
Initial Operational Capability (IOC)
1998
Total Production
45
Specifications (Deagel)
Crew
2
External Stations
8
Number of Engines
1
Area — Wing Area
30 square meter
Dimensions — Height
4.5 meter
Dimensions — Length
14.8 meter
Dimensions — Main Gun Caliber
27 millimeter
Dimensions — Wingspan
8.4 meter
G-load — Max Maneuvering Load Factor
9 g
G-load — Min Maneuvering Load Factor
-3.00 g
Mass — Empty Weight
6,800 kilogram
Mass — Max Takeoff Thrust
18,100 pound
Mass — Max Takeoff Weight
14,000 kilogram
Mass — Payload
5,300 kilogram
Performance — Ceiling
15,240 meter
Performance — Ferry Range
3,200 kilometer
Performance — Landing Run Distance
500 meter
Performance — Radius of Operation
800 kilometer
Performance — Take Off Run Distance
400 meter
Speed — Cruise Speed
0.80 mach
Speed — Supercruise Speed
1.1 mach
Speed — Top Speed at High Altitude
2 mach
Gear (Deagel)
Item 1
Air-to-Air Missiles: A-Darter
Item 2
Air-to-Air Missiles: AIM-120B AMRAAM
Item 3
Air-to-Air Missiles: AIM-9M Sidewinder
Item 4
Air-to-Air Missiles: IRIS-T
Item 5
Air-to-Air Missiles: Meteor
Item 6
Anti-Ship Missiles: RBS15 Mk3
Item 7
Bombs: GBU-12 Paveway II
Item 8
Bombs: GBU-39/B (16)
Item 9
Bombs: GBU-49 Paveway II
Item 10
Decoy Systems: BOL
Item 11
Decoy Systems: BOP/B
Item 12
ESM & Warning Systems: BOW-21
Item 13
Fighter Aircraft Engines: RM12 (1)
Item 14
Helmets: Cobra (2)
Item 15
Jamming Systems: EWS39
Item 16
Medium Caliber Cannons: BK 27 (1)
Item 17
Optronic Systems: DJRP (1)
Item 18
Optronic Systems: IR-OTIS (1)
Item 19
Optronic Systems: LITENING (1)
Item 20
Optronic Systems: MRPS (1)
Item 21
Radar Systems: PS-05/A (1)
Item 22
Standoff Weapons: AFDS
Variants
Variant 1
JAS 39C Gripen
Variant 2
JAS 39D Gripen
Variant 3
JAS 39E Gripen
Variant 4
JAS 39F Gripen
Details
Country of Origin
Sweden
Category
Multirole Aircraft
Air > Multirole Aircraft
Sources
deagel.com: https://www.deagel.com/x/x/a000532
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
14.8 m
Width
8.4 m
Height
4.5 m
Weight
14000 kg
Related Equipment (1)
Variant of
Operators (6)
Ukraine
Sweden
South Africa
Czech Republic
Hungary
Thailand
