Basic Information

Name

SR98 Australian 7.62mm Sniper Rifle

Designation

SR98

Alternate Designation

SR98

Equipment Type

Sniper Rifle

Manufacturer

Accuracy International

Date of Introduction

1990

Description

The SR98 Australian 7.62mm Sniper Rifle is the Australian version of the Accuracy International Arctic Warfare rifle is a bolt-action sniper rifle. The Accuracy International Arctic Warfare rifle is a bolt-action sniper rifle designed and manufactured by the British company Accuracy International. It has proved popular as a civilian, police, and military rifle since its introduction in the 1980s. The rifles have some features that improve performance in very cold conditions (which gave the rifle its name) without impairing operation in less extreme conditions. Arctic Warfare rifles are generally fitted with a Schmidt & Bender PM II telescopic sight with fixed or variable magnification. Variable telescopic sights can be used if the operator wants more flexibility to shoot at varying ranges, or when a wide field of view is required. Accuracy International actively promotes fitting the German-made Schmidt & Bender MILITARY MK II product line as sighting components on their rifles, which is rare for a rifle manufacturer. The German and Russian forces preferred a telescopic sight made by Zeiss[4] over Accuracy International's recommendation. The AW system is almost unique in being a purpose-designed military sniper rifle, rather than an accurised version of an existing general-purpose rifle. The modular design of the AW system allows for flexibility, serviceability and repairability under field and combat conditions. Major components, such as the barrel and the bolt, can be switched between rifles, or replaced in the field by their operator with the help of some tools. The chambering can also be switched by the operator as long as the barrels, bolts and feeding mechanism can handle the shape and size of the cartridges. Rather than a traditional wooden or polymer rifle stock, the AW is based on an aluminium chassis which extends the entire length of the stock. This chassis system is marketed as the Accuracy International Chassis System (AICS) and can be used for all Accuracy International rifles. All other components, including the receiver, are bolted directly to this chassis. Two hollow polymer "half thumb-hole stock panels", usually coloured green, dark earth or black, are in turn bolted to each other through the chassis, creating a rugged yet, for its sturdiness, comparatively light weapon. The Accuracy International receiver is bolted with four screws and permanently bonded with epoxy material to the aluminium chassis, and was designed for ruggedness, simplicity and ease of operation. To this end, the heavy-walled, flat-bottomed, flat-sided receiver is a stressed part, machined in-house by AI from a solid piece of forged carbon steel. AW rifles are supplied in two action lengths—standard AW (short) and long SM (magnum). The six bolt lugs, arranged in two rows of three, engage a heat-treated steel locking ring insert pinned inside the front bridge of the action. The ring can be removed and replaced to refresh headspace control on older actions. The AW system cast steel bolt has a 0.75-inch (19.05 mm) diameter combined with gas relief holes in a 0.785 in (19.9 mm) diameter bolt body and front action bridge allowing high-pressure gases a channel of escape in the event of a cartridge-case head failure. Against penetrating water or dirt the bolt has milled slots, which also prevent freezing or similar disturbances. Unlike conventional bolt-action rifles, the bolt handle is bent to the rear, which eases the repeating procedure for the operator and reduces the contour of the weapon. The action cocks on opening with a short, 60 degree bolt throw and has a non-rotating (fixed) external extractor and an internal ejector. Firing pin travel is 0.26 in (6.6 mm) to keep lock times to a minimum. Finally, an 11 mm (0.43 in) integral dovetail rail located above the receiver is designed to accommodate different types of optical or electro-optical sights. As an option, a MIL-STD-1913 rail (Picatinny rail) can be permanently pinned, bonded and bolted to the action, providing a standard interface for many optical systems.

Variants

PM (Precision Marksman) The rifle from which the Arctic Warfare family was developed. In this original form, it entered service in the UK in the mid-1980s, and designated as the L96A1 (chambered for 7.62×51mm NATO).

AW (Arctic Warfare) The basic 'improved' version of the L96A1. The name stems from special features designed to enable operation in extremely cold climates. Adopted as the following (All versions mentioned are chambered for the 7.62×51mm NATO cartridge and uses a 10-round detachable magazine): L118A1: The British military service version. Psg 90: The Swedish military service version. Psg is short for Prickskyttegevär ("Sniper Rifle"). SR98: The Australian military service version. It is the standard issue sniper rifle for the Australian Army and is also used by various law enforcement agencies. This variant features threaded barrel (for a suppressor), an integrated adjustable bipod, a free floating barrel and a folding stock with adjustable butt pad, cheek pad, and a rear mono pod.

AWF (Arctic Warfare Folding) The AWF is a variant of the AW with side-folding polymer stock. L118A2: The British military service version. Psg 90B: The Swedish military service version.

AWP (Arctic Warfare Police) The AWP is a version intended for use by law enforcement as opposed to military, with AWP standing for Arctic Warfare Police. The most notable feature is that the distinctive frame is black instead of light green. It also has a shorter 24 in (610 mm) barrel than the AW model. The AWP is normally chambered for 7.62×51mm NATO/.308 Winchester or .243 Winchester ammunition, though it can be chambered for other cartridges. The AWP is distinct from the Accuracy International AW AE, which also has a black finish but is a cheaper non-military version of the AW series.

AWS (Arctic Warfare Suppressed) The AWS is specifically designed for use with subsonic ammunition which, depending on the target, gives an effective maximum range of around 300 metres (330 yd). Its noise levels are similar to those generated by .22 LR match ammunition. The weapon is fitted with a special .308 Winchester/7.62×51mm NATO 406 mm (16 in) long barrel which has a twist rate of 229 mm (1 in 9 in) and an integral suppressor. The AWS barrel/suppressor combination has a total length of 711 mm (28 in), which keeps the weapon's overall length within normal limits. The user can remove the barrel/suppressor combination and replace it with a standard AW or AWP barrel in about three minutes. As with all such systems, the sight will need re-zeroing after a barrel change.

AWC (Arctic Warfare Covert) The Covert system is essentially an AWS with a folding stock with a 305 mm (12 in) long barrel/suppressor combination with a 203 mm (1 in 8 in) twist rate. It is supplied in a small suitcase which houses the rifle with the stock folded and the barrel/suppressor combination detached. The polymer suitcase is lined with closed-cell foam featuring cut-outs for the stock/action/optics/bipod combination, the bolt, the suppressor, a magazine and a box of ammunition. While the Covert system's compacted size is considerably smaller than that of any conventional system, its special barrel and integral suppressor keep the weapon's overall length within normal limits when deployed.

AWM (Arctic Warfare Magnum) The AWM is a variant of the AW sniper rifle that is chambered for either the .300 Winchester Magnum or the .338 Lapua Magnum. It has a longer bolt compared to the AW, in order to accommodate for the larger and more powerful magnum cartridges. It's fed through a 5-round detachable magazine. The AWM that is chambered for the .338 Lapua Magnum cartridge has been adopted since its first introduction in the British army and in the Dutch army in 1996.

AWM-F (Arctic Warfare Magnum Folding Stock) The AWM-F was the first AW variant featuring a folding stock and has been adopted since its first introduction in the German Army in 1998, and by other several armies: (See the Arctic Warfare Magnum to see the full list.) The G22 (Gewehr 22 or Scharfschützengewehr 22) by German Army, it features a folding stock and is chambered for the .300 Winchester Magnum round (designated 7.62×67mm). The Dutch army also adopted the AWM-F that is chambered for the .338 Lapua Magnum.

AW50 (Arctic Warfare .50 calibre) The AW50 was introduced in 2000 by the British and Australian armed forces and is an AW rifle re-engineered and chambered for .50 BMG (12.7×99mm NATO). The German Army adopted the AW50 and designated it as the G24 (Gewehr 24 or Scharfschützengewehr 24).

AW50F (Arctic Warfare .50 calibre Folding Stock) The AW50F is a variant of the AW50 adopted by the Australian military. It differs from the standard AW50 in that it is fitted with a folding stock (hence the F) and Maddco barrel.

AE (Accuracy Enforcement) The Accuracy International AE was introduced in 2001 as a cheaper, somewhat simplified, less robust version of the L96/AW series intended for law enforcement, in place of the more expensive AWP or AW models intended for military use. The AE bolt-action differs from the larger, more angular AW design. The round AE receiver is lighter than in the AW models. The action of the AE is not permanently bonded with epoxy material to the aluminium chassis and can be removed. Unlike the AW models, the AE can not be ordered in a left-handed configuration. The AE is chambered in 7.62×51mm NATO cartridge and its barrel is 610 mm (24 in) long.

AE Mk III In 2009, the AE was updated to the AE Mk III. The AE Mk III sniper rifle system uses AICS 5- and 10-round magazines, has a removable trigger group, and a screw-adjustable cheekpiece. An optional 508 mm (20.0 in) barrel with muzzle brake or tactical suppressor mounting facilities and a folding chassis are available. Accuracy International has discontinued the AE sniper rifles. In 2014, Accuracy International introduced the AT308 or the AT (Accuracy Tactical) sniper rifle, which is a more modern variant of the AE (Accuracy Enforcement) sniper rifle, and will be offered to law enforcement and civilian clients worldwide.

AT (Accuracy Tactical) The AT (Accuracy Tactical) model was introduced in 2014 as a cheaper alternative to the more expensive AX series which are intended for military use. The AT on the other hand is intended for law enforcement and civilian use. Like the AX series the AT continues the legacy of the Arctic Warfare sniper rifle and is also an improvement of the AE (Accuracy Enforcement) sniper rifle. The AT is chambered in 7.62×51mm NATO/.308 Winchester. It is a manual operated, bolt action sniper rifle. It features a rotary bolt with six locking lugs, arranged into three pairs at the bolt head, a polymer stock with aluminium alloy chassis, and a solid, flat-bottomed receiver made of steel, the AI (Accuracy International) muzzle brake (optional), a detachable suppressor, a 20-, 24- inch plain or threaded barrel, and a 26-inch threaded barrel only, a 10-round detachable magazine, an integral Picatinny (Mil-Std 1913) rail above the receiver for mounting various optics/scopes and an additional accessory rails can be easily bolted to the forend of the rifle for mounting various accessories, a standard stock that is made from a polymer and features fully adjustable comb and buttpad, side-folding stock that folds to the left is available, a two-stage trigger that is adjustable for trigger weight between 1.5 and 2 kg.

System

Alternate Designation SR98

Type Sniper Rifle

Manufacturer Accuracy International

In Service 1990s-Present

Action Bolt-action

Muzzle Velocity 850 m/s

Maximum Firing Range 3,943 m

Effective Firing Range 800 m

Feed System 10-round double stack detachable box magazine (.308) 5-round single stack detachable box magazine (.300, .338)

Sights detachable aperture type iron sights day or night optics

Dimensions

Length 1,180 mm

Barrel Length 660 mm

Weight 6.5 kg

Ammunition

Type Rifle

Caliber 7.62mm

Cartridge 7.62×51mm NATO

Available Cartridge 7.62×51mm NATO (.308 Winchester) .300 Winchester Magnum .338 Lapua Magnum
