Hai Lung

Hai Lung

Attack Submarines
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Hai Lung
Designation
Hai Lung
Alternate Designation
Zwaardvis
Equipment Type
Attack Submarines
Manufacturer
—
Date of Introduction
1987
Description

The Hai Lung, also known as Zwaardvis, class conventional attack submarine (SSK) was designed and built in the Netherlands for the Navy of Taiwan. These 2,600-ton class boats are intended to engage hostile submarines and surface ships in the open sea (blue water operations). They feature six 21-inch (533mm) torpedo tubes with enough room for 28 torpedoes. The ship's sensor builds around SIASS hull-mounted sonar. The diesel-electric propulsion system uses relies on three diesel engines developing 5,100-shp and a top speed of 20 knots submerged. The Navy of Taiwan commissioned two Hai Lung class boats in 1987 and 1988. There were plans for further submarines but the Netherlands cancelled this project ahead of schedule.

Naval & Littoral Specifications
Crew 67
Beam 8.40 m
Draft 6.70 m
Overview (Deagel)
Group Attack Submarines
Status Active
Also Known As Zwaardvis
Origin Netherlands
Initial Operational Capability (IOC) 1987
Total Production 2
Specifications (Deagel)
Crew 67
Number of Engines 3
Number of Weapons 28
Torpedo Tubes 6
Dimensions — Beam 8.4 meter
Dimensions — Draft 6.7 meter
Dimensions — Length 66.9 meter
Mass — Displacement Submerged 2,660 ton
Power — Power 5,100 shp
Speed — Top Speed Submerged 20 knot
Details
Country of Origin Netherlands
Category Submarines
Naval > Submarines
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
66.9 m
Width
8.4 m
Height
—
Weight
—
Operators (1)
Taiwan
