Angara A5V

Angara A5V

Space Launch Systems
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Angara A5V
Designation
Angara A5V
Alternate Designation
A5B, Angara 5P, Angara-5B
Equipment Type
Space Launch Systems
Manufacturer
Khrunichev Space Center
Date of Introduction
2031
Description

The Angara A5V is a two-stage, heavy-lift space launch vehicle comprising six Common Core Boosters (CCBs) at the first stage, including five boosters; one 66,200-lb RD-0124 motor at the second stage; and the hydrogen powered Breeze M or KVRB upper stage. Basically the A5V adds an extra booster to the Angara A5 rocket carrier to lift super-heavy payloads. The decision to develop the A5V carrier was taken in April 2015 instead of developing a new super-heavy carrier. The first launch of the Angara A5V heavy-lift space rocket is expected for 2025. It is expected that the Angara A5V will carry a manned crew to the Moon by 2030. The Angara 5P variant was projected to carry the Orel spacecraft by the mid 2020s, but finally the project was cancelled. The Angara A5V first launch is planned in 2030 with a resusable first and second stage and the hydrogen powered KVTK upper stage.

Air & Air Defense Specifications
Range 36000.0 km
Overview (Deagel)
Group Space Launch Systems
Status Under Development
Also Known As A5B, Angara 5P, Angara-5B
Origin Russia
Contractor Khrunichev Space Center
Initial Operational Capability (IOC) 2031
First Flight 2030
Total Production 1
Specifications (Deagel)
Crew 0
Number of Stages 3
Dimensions — Rocket Diameter 4.4 meter
Mass — Max Lift-off Thrust 1,404 ton
Mass — Payload to GEO 30 ton
Mass — Payload to LEO 37.5 ton
Performance — Orbit 36,000 kilometer
Gear (Deagel)
Item 1 Rocket Engines: RD-0124A (1)
Variants
Variant 1 Angara 1.1
Variant 2 Angara A3
Variant 3 Angara A7
Variant 4 Angara 1.2
Variant 5 Angara A5
Variant 6 Angara A5M
Variant 7 Angara A5V
Details
Country of Origin Russia
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
4.4 m
Height
Weight
1404000 kg
Operators (1)
Russia
