K808
K808
Wheeled Armored Vehicles
Basic Information
Name
K808
Designation
K808
Alternate Designation
KW2 Scorpion
Equipment Type
Wheeled Armored Vehicles
Manufacturer
Hyundai Rotem
Date of Introduction
2018
Description
The KW2 Scorpion 8x8 armored vehicle is a 17-ton class vehicle available as infantry carrier vehicle (ICV), armored combat vehicle (ACV) fitted with a turret-mounted 30mm gun, anti air-gun vehicle (AAGV), and mortar carrier vehicle (MCV) equipped with a 120mm mortar weapon system. Its primary armament consists of remote weapon station fitted with a 40mm automatic grenade launcher (AGL) and a 7.62mm machine gun and a 12.7mm machine gun as secondary armament. The vehicle entered service with RoKA as the K808.
Ground Specifications
Crew
2
Troop Capacity
10
Max Speed
110.0 km/h
Range
800.0 km
Overview (Deagel)
Group
Wheeled Armored Vehicles
Status
Active
Also Known As
KW2 Scorpion
Origin
South Korea
Contractor
Hyundai Rotem
Initial Operational Capability (IOC)
2018
Total Production
?
Unitary Cost
USD $2 million
Specifications (Deagel)
Crew
2
Troops
10
Wheel Drive
8
Wheels
8
Dimensions — Height
2.9 meter
Dimensions — Length
7.4 meter
Dimensions — Main Gun Caliber
30 millimeter
Dimensions — Width
2.7 meter
Mass — Combat Weight
20 ton
Percentage — Gradient
60 %
Percentage — Side Slope
30 %
Performance — Ditch Crossing Ability
2 meter
Performance — Max Range
800 kilometer
Performance — Step Climbing Ability
0.50 meter
Performance — Turning Radius
9 meter
Power — Power
420 hp
Speed — Top Speed
110 kph
Speed — Top Swimming Speed
10 kph
Variants
Variant 1
K806
Variant 2
K808
Details
Country of Origin
South Korea
Sources
deagel.com: https://www.deagel.com/x/x/a002459
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.4 m
Width
2.7 m
Height
2.9 m
Weight
20000 kg
Operators (2)
South Korea
Peru
