KC-130J Super Hercules

KC-130J Super Hercules

Tanker Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
KC-130J Super Hercules
Designation
KC-130J Super Hercules
Alternate Designation
Battle Herks, Harvest Hawk (US Marine Corps attack variant), Super Hercules
Equipment Type
Tanker Aircrafts
Manufacturer
Lockheed Martin
Date of Introduction
2003
Description

The KC-130J is an air tanker aircraft derived from the shorter fuselage C-130J cargo aircraft. It provides in-flight refueling for both tactical aircraft and helicopters and can refuel two aircraft simultaneously. They have a 57,500 pound (8,455 US gallons) fuel offload capability while being flown on a 500 nm (900 km) radius mission. The KC-130J is also configured to accept a fuselage tank, which adds another 24,392 pounds (3,600 US gallons) of available offload to a mission. The USMC plans to purchase up to 79 KC-130J for the replacement of current KC-130F/R/T tankers. According to some sources the total number of KC-130J required by the USMC could be as high as 107 to provide in-flight refueling services to MV-22 and F-35 aircraft fleets well into the 21st century. In late April 2004, following the KC-130J operational testing program carried out between October 2003 and January 2003, the USMC officials recommended full fleet introduction of KC-130J tanker aircraft. During the testing the new tanker aircraft outperformed KC-130T while demonstrating increased capabilities over legacy KC-130s. The US Marine Corps exercised an option for a second KC-130J Weapons System Trainer (WST) on February 2, 2005, as part of a contract worth $73 million signed in 2004. The USMC retained an option on a third KC-130J WST. As of early 2005, Marines had 33 KC-130J tanker aircraft on order with 15 tankers delivered at that time. The Italian Air Force (Aeronautica Militare Italiana) began C-130J procurement in 1997 with an order for 18 aircraft, two more aircraft were ordered in 1999 and two more in 2000 totaling 22 C-130J Super Hercules. These aircraft replaced aging C-130Hs operated by Italy. Six of the 12 short fuselage C1-30Js were modified to KC-130J tanker aircraft adding a capability the Italian Air Force has not had previously.

Air & Air Defense Specifications
Crew 5
Max Speed 705.6 km/h
Range 4390.0 km
Service Ceiling 10058 m
Wingspan 39.70 m
Overview (Deagel)
Group Tanker Aircrafts
Status Active
Also Known As Battle Herks, Harvest Hawk (US Marine Corps attack variant), Super Hercules
Origin United States of America
Contractor Lockheed Martin
Initial Operational Capability (IOC) 2003
Total Production 92
Unitary Cost USD $82 million
Specifications (Deagel)
Crew 5
Number of Engines 4
Dimensions — Height 11.4 meter
Dimensions — Length 29.3 meter
Dimensions — Wingspan 39.7 meter
Mass — Max Takeoff Weight 70,308 kilogram
Performance — Ceiling 10,058 meter
Performance — Max Range 4,390 kilometer
Power — Max Power at TakeOff 18,364 shp
Speed — Top Speed at High Altitude 196 mps
Gear (Deagel)
Item 1 Anti-Tank Glider Weapons: GBU-44/B Viper Strike
Item 2 Anti-Tank Guided Missiles: Griffin A
Item 3 ESM & Warning Systems: AN/ALR-56
Item 4 Jamming Systems: ELT/572
Item 5 Radar Systems: AN/APN-241 (1)
Item 6 Turboprop Engines: AE 2100D3 (4)
Variants
Variant 1 C-130H Hercules
Variant 2 MC-130H Talon II
Variant 3 AC-130U Spooky
Variant 4 C-130J Super Hercules
Variant 5 CC-130J Super Hercules
Variant 6 KC-130J Super Hercules
Variant 7 WC-130J
Variant 8 MC-130W Combat Spear
Variant 9 EC-130J Commando Solo
Variant 10 MC-130J Commando II
Variant 11 AC-130J Ghostrider
Variant 12 LM-100J
Variant 13 C-130J-SOF
Details
Country of Origin United States
Category Aerial Refueling Aircraft
Air > Aerial Refueling Aircraft
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
29.3 m
Width
39.7 m
Height
11.4 m
Weight
70308 kg
Operators (5)
United States
France
Italy
Kuwait
Saudi Arabia
