Argus

Naval Radar

Spotted an error? Sign in to suggest an edit.

Basic Information

Name

Argus

Designation

—

Alternate Designation

—

Equipment Type

Naval Radar

Manufacturer

Simrad Yachting

Date of Introduction

1852

Description

The Argus is a naval navigation radar system manufactured by Simrad Yachting, operating in the S-band with a peak power of 30 kW. It employs a multi-radar configuration to minimize blind zones, typically featuring a long-range S-band unit mounted high on the mast, complemented by shorter-range units at the bow and stern. These additional units can be either pulsed Halo radars or Simrad 4G broadband radars (FMCW). The system offers pulse repetition frequencies of 0.75, 1.5, or 3 kHz, pulsewidths of 0.06, 0.25, or 0.8 µs, and an instrumented range of 40 nautical miles (74 km), with a beamwidth of 1.9° and an antenna rotation speed of 20 revolutions per minute.

Naval & Littoral Specifications

Range 40.0 nm

Technical Characteristics

frequency S band

pulse repetition frequency (PRF) 0.75; 1.5; 3 kHz

pulsewidth (τ) 0.06; 0.25; 0.8 µs

peak power 30 kW

instrumented range 40 NMNM(≙ 74 km)

beamwidth 1.9°

antenna rotation 20 min⁻¹

Details

Country of Origin United Kingdom

Category Sea Based Sensors

Naval > Sea Based Sensors

Sources

radartutorial.eu: https://www.radartutorial.eu/19.kartei/07.naval2/karte067.en.html Wikidata (https://www.wikidata.org/wiki/Q112159456)

Classification

Domain

Naval & Littoral

Equipment Status

Active

Operators (1)

Portugal
