SUPERAV LAND Italian 8x8 Armored Personnel Carrier (APC)

SUPERAV LAND

Amphibious Armored Personnel Carrier (APC)

Spotted an error? Sign in to suggest an edit.

SUPERAV LAND Italian 8x8 Armored Personnel Carrier (APC) — SUPERAV LAND Italian 8x8 APC (A)TRADOC ODIN WEG

Basic Information

Name

SUPERAV LAND Italian 8x8 Armored Personnel Carrier (APC)

Designation

SUPERAV LAND

Alternate Designation

SUPERAV LAND

Equipment Type

Amphibious Armored Personnel Carrier (APC)

Manufacturer

Iveco Defense Vehicles

Date of Introduction

2025

Description

The SUPERAV LAND Italian 8x8 Armored Personnel Carrier (APC) is a land-optimized variant of the proven SUPERAV amphibious platform developed by IVECO Defence Vehicles (IDV), unveiled in 2025 as an addition to the company's tactical armored vehicle lineup. This vehicle represents a significant evolution in land-focused operations while maintaining substantial component commonality with its amphibious predecessor. The development of the SUPERAV Land reflects market demand for a dedicated land-operations platform following the international success of the amphibious variant, which was selected by the United States Marine Corps for the Amphibious Combat Vehicle (ACV) program and by the Italian Navy for the VBA (Veicolo da Battaglia Anfibio) program. The modular design and component commonality position the SUPERAV Land as a flexible platform for modern armed forces seeking cost-effective solutions for diverse battlefield missions.

Ground Specifications

Crew 3

Mobility Type Wheeled (8x8)

Engine Turbocharged Diesel (700 hp)

NBC Protection Yes

Max Speed 105.0 km/h

Range 700.0 km

System

Alternative Designation SUPERAV LAND

Type Armored Personnel Carrier (APC)

Manufacturer Iveco Defense Vehicles

Configuration 8x8

Crew 3 ea

Passengers 8 ea

Payload Capacity 4,000 kg

Internal Volume 16.0 m3

Note The SUPERAV Land incorporates a digital vetronic suite with 900 ampere-hours of onboard electrical power, enabling third-party subsystem integration with built-in diagnostics for improved maintainability.

Dimensions

Length 8,300 mm

Width 3,120 mm

Height 2,600 mm

Weight, Combat 31,500 kg

Automotive

Engine Name Iveco Cursor 16

Engine Type Turbocharged diesel

Engine Power 700 hp

Maximum Range 700 km

Maximum Speed 105 km/h

Amphibious No

Gradient 60%

Side Slope 30%

Vertical Step 0.65 m

Trench 2.0 m

Fording 1.5 m

Main Weapon System

Note The vehicle can be equipped with weapon systems up to 40mm caliber through various mounting options, including remotely-controlled turrets that preserve troop capacity while enhancing firepower.

Protection

Armor Unlike the original amphibious variant, the Land model eliminates amphibious subsystems such as propellers, bilge pumps, and trim vanes, freeing mass allocation for enhanced ballistic protection. The weight savings from eliminating amphibious systems and reducing troop capacity from 13 to 8 personnel—equivalent to approximately 800 kilograms—are reinvested in additional protection levels. The structural design incorporates a high-strength monocoque steel hull capable of withstanding small arms fire, artillery shell splinters, mines, and IED attacks.

Applique Armor Add-on armor kits are available for further protection enhancement.

NBC Protection Yes

Smoke Equipment 8 x smoke grenade launchers.

Image Sources

Notes https://www.idvgroup.com/products/land-armoured-vehicles/superav-land/

Details

Country of Origin Italy

Category Land

Land

Classification

Domain

Ground

Equipment Status

Active

Dimensions

Length

8.3 m

Width

3.12 m

Height

2.6 m

Weight

31500 kg

Operators (2)

United States

Italy
