Project 22356

Project 22356

Frigates
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Project 22356
Designation
Project 22356
Alternate Designation
—
Equipment Type
Frigates
Manufacturer
Severnaya Verf, Severnoye Design Bureau
Date of Introduction
2025
Description

The Project 22356 is a variant of the Russian Navy Project 22350 multipurpose stealth frigate intended for the export market. No orders have been announced so far for this new multipurpose surface combatant ship. The weapon system consists of a 130mm A-192 naval gun, the Club-NKE missile family along with Yakhont supersonic-anti-ship missiles. The air defense system consists of the Shtil-1 medium-range missile system or the Rif-M long-range missile system. Close-range air defense is provided by either two Palma gun/missile system or two AK-630M gun systems. The vessel is equipped with the Paket anti-submarine/anti-torpedo torpedo system. A flight deck and hangar support a 12-ton class helicopters. It is likely that this new ships will accept sensors and weapons systems supplied from third parties. Nevertheless, the standard equipment includes the Fregat MAE-5 radar and Zarya-ME-03 sonar system. All in, the Project 22356 is a downgraded variant of the Project 22350 intended for the export market.

Naval & Littoral Specifications
Crew 215
Displacement 4750.00 tonnes
Beam 16.40 m
Draft 4.70 m
Max Speed 29.5 knots
Overview (Deagel)
Group Frigates
Status Cancelled
Origin Russia
Contractors Severnaya Verf, Severnoye Design Bureau
Initial Operational Capability (IOC) 2025
Total Production ?
Specifications (Deagel)
Crew 215
Number of Aircraft 1
Number of Engines 2
Number of Weapons 52
Dimensions — Beam 16.4 meter
Dimensions — Draft 4.7 meter
Dimensions — Length 135 meter
Dimensions — Main Gun Caliber 130 millimeter
Mass — Full Displacement 4,750 ton
Performance — Max Range 4,500 nautical mile
Power — Electric Output 4,000 kW
Power — Total Combined Power 54,400 hp
Speed — Cruise Speed 18 knot
Speed — Economical Speed 14 knot
Speed — Top Speed 29.5 knot
Time — Mission Endurance 30 day
Gear (Deagel)
Item 1 Anti-Ship Missiles: 3M54TE (16)
Item 2 Anti-Ship Missiles: 3M54TE1 (16)
Item 3 Anti-Ship Missiles: Onyx (16)
Item 4 Anti-Submarine Rockets: 91RTE2 (16)
Item 5 ASW Helicopters: Ka-27 (2)
Item 6 Missile Launchers: 3S-14 (2)
Item 7 Naval Gun Systems: AK-192 (1)
Item 8 Naval Gun Systems: AK-630M (2)
Item 9 Radar Systems: 5P-10 (1)
Item 10 Radar Systems: Fregat MAE-5 (1)
Item 11 Sea-Based Air Defense Systems: Palma (1)
Item 12 Sea-Based Air Defense Systems: Rif-M (1)
Item 13 Sea-Based Air Defense Systems: Shtil-1 (1)
Item 14 Ship Power Plants: M90FRU
Item 15 Sonar Systems: Zarya-ME-03 (1)
Item 16 Surface-to-Air Missiles: 9M317M (36)
Item 17 Torpedoes: Paket (8)
Variants
Variant 1 Project 22350
Variant 2 Project 22356
Variant 3 Project 22351
Variant 4 Project 22350M
Details
Country of Origin Russia
Category Frigates
Naval > Frigates
Sources

deagel.com: https://www.deagel.com/x/x/a002255

Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
135 m
Width
16.4 m
Height
—
Weight
4750000 kg
Related Equipment (1)
Variant of

Admiral Gorshkov Class (Project 22350 Class) Russian Frigate

FrigateRussia
