ATR 42 Surveyor

ATR 42 Surveyor

Maritime Patrol Aircrafts
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
ATR 42 Surveyor
Designation
ATR 42 Surveyor
Alternate Designation
ATR 42 MP
Equipment Type
Maritime Patrol Aircrafts
Manufacturer
ATR
Date of Introduction
2008
Description

The ATR 42 Surveyor, also known as the ATR 42 MP, is a derivative of proven ATR 42 commercial aircraft developed to conduct maritime patrol missions and coastal surveillance. It can load the wide spectrum of equipment required to conduct that kind of missions such as radar, FLIR, TV camera, Electronic Support Measures (ESM), Communications and Navigation systems. In addition, bubble panoramic windows have been provided to the Surveyor for optimal visual observation of the environment. The ATR 42 Surveyor can remain on station for up to 8 hours at 200 nautical miles from its base airfield. To do so, the aircraft cruises at low loiter speed which facilitates target detection and tracking while it can change to higher speed at any time. The Italian Customs service ordered two ATR 42 MP and the Italian Coast Guard an undisclosed number of airplanes to protect Italy's Economic Exclusive Zone (EEZ).

Air & Air Defense Specifications
Range 750.0 km
Service Ceiling 3750 m
Wingspan 24.50 m
Overview (Deagel)
Group Maritime Patrol Aircrafts
Status Active
Also Known As ATR 42 MP
Origin France, Italy
Contractor ATR
Initial Operational Capability (IOC) 2008
Total Production 11
Unitary Cost EUR €31 million
Specifications (Deagel)
Number of Engines 2
Dimensions — Height 7.6 meter
Dimensions — Length 22.7 meter
Dimensions — Wingspan 24.5 meter
Mass — Empty Weight 11,250 kilogram
Mass — Max Takeoff Weight 18,600 kilogram
Mass — Payload 5,450 kilogram
Performance — Ceiling 3,750 meter
Performance — Max Range 750 kilometer
Power — Max Power at TakeOff 4,800 shp
Speed — Cruise Speed 155 mps
Time — Flight Endurance 8 hour
Gear (Deagel)
Item 1 Radar Systems: Gabbiano (1)
Item 2 Turboprop Engines: PW100 (2)
Variants
Variant 1 ATR 42
Variant 2 ATR 72
Variant 3 ATR 42 Surveyor
Variant 4 ATR 72 ASW
Variant 5 ATR 72-600
Variant 6 ATR 42-600
Variant 7 ATR 72-600F
Variant 8 ATR NEO
Details
Country of Origin France
Category Maritime Patrol
Air > Maritime Patrol
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
22.7 m
Width
24.5 m
Height
7.6 m
Weight
18600 kg
Operators (3)
Italy
Libya
Nigeria
