Project 11356R

Project 11356R

Frigates
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Project 11356R
Designation
Project 11356R
Alternate Designation
Admiral Grigorovich, Burevestnik-M, Project 1135.7, Project 11356M
Equipment Type
Frigates
Manufacturer
Severnoye Design Bureau, Yantar
Date of Introduction
2016
Description

The Project 11356M, also known as Project 1135.7, is an improved Project 11356 class frigate ordered by the Russian Navy. Project 11356M frigates are equipped with the Shtil-1 medium range air defense system with 24 9M38 missiles and one 3S-14E eight-tube under-deck launcher with eight 3M-54TE/Club-N supersonic anti-ship missiles. In addition, the ship is provided with one 100mm A190-01 naval gun, two Kashtan close-in weapon systems with 64 9M311-1 missiles, a RBU-6000 12-tube anti-submarine warfare (ASW) mortar, and two double 533mm tubes for SET-65K torpedoes. Additional protection is provided with the ship's Electronic Counter-Measures (ECM) and decoy systems. Russian placed an order for three ships to be based in the Black Sea fleet in 2010 and a second order for three additional vessels in 2011. The Russian expects to commission six Project 11356M frigates between 2015 and 2017. The sixth and last vessel construction was cancelled in 2014. In July 2017 the Russian Navy stated that was going to built the remaining three frigates despite Ukraine not supplying the gas turbines.

Naval & Littoral Specifications
Crew 180
Displacement 4035.00 tonnes
Beam 15.20 m
Draft 4.20 m
Max Speed 30.0 knots
Overview (Deagel)
Group Frigates
Status Active
Also Known As Admiral Grigorovich, Burevestnik-M, Project 1135.7, Project 11356M
Origin Russia
Contractors Severnoye Design Bureau, Yantar
Initial Operational Capability (IOC) March 10, 2016
Total Production 5
Unitary Cost USD $530 million
Specifications (Deagel)
Ammunition Load 500
Crew 180
Enlisted 162
Number of Aircraft 1
Number of Weapons 32
Officers 18
Dimensions — Beam 15.2 meter
Dimensions — Draft 4.2 meter
Dimensions — Length 125 meter
Dimensions — Main Gun Caliber 100 millimeter
Mass — Full Displacement 4,035 ton
Mass — Standard Displacement 3,850 ton
Performance — Max Range 4,850 nautical mile
Power — Total Combined Power 56,000 hp
Speed — Cruise Speed 14 knot
Speed — Top Speed 30 knot
Time — Mission Endurance 30 day
Gear (Deagel)
Item 1 Anti-Ship Missiles: 3M54TE/Club-N (8)
Item 2 Anti-Ship Missiles: Onyx (8)
Item 3 Anti-Submarine Rockets: RBU-6000 (1)
Item 4 ASW Helicopters: Ka-27PL (1)
Item 5 Cruise Missiles: Kalibr-PL (8)
Item 6 Naval Gun Systems: A190-01 (1)
Item 7 Naval Gun Systems: AK-630M (2)
Item 8 Radar Systems: 3TS-25E (1)
Item 9 Radar Systems: Fregat M2EM (1)
Item 10 Sea-Based Air Defense Systems: Kashtan (2)
Item 11 Sea-Based Air Defense Systems: Shtil-1 (1)
Item 12 Ship Power Plants: DS-71 (2)
Item 13 Ship Power Plants: DT-59 (2)
Item 14 Ship Power Plants: M90FRU (2)
Item 15 Surface-to-Air Missiles: 9M311-1 (64)
Item 16 Surface-to-Air Missiles: 9M317M (24)
Item 17 Torpedoes: SET-65K (4)
Variants
Variant 1 Project 11356
Variant 2 Project 11356R
Variant 3 Triput
Details
Country of Origin Russia
Category Frigates
Naval > Frigates
Sources

deagel.com: https://www.deagel.com/x/x/a001904

Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
125 m
Width
15.2 m
Height
—
Weight
4035000 kg
Related Equipment (1)
Variant of

Admiral Grigorovich Class (Project 11356 Class) Russian Frigate

FrigateRussia
View details
Operators (2)
Russia
India
