TATRA T 815-2

TATRA T 815-2

Military Trucks
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
TATRA T 815-2
Designation
TATRA T 815-2
Alternate Designation
Equipment Type
Military Trucks
Manufacturer
TATRA
Date of Introduction
Description

The TATRA ARMAX, also known as T 815-2, is a family of all wheel drive vehicles designed to be operated in difficult terrains and climate conditions as well as to support peacekeeping missions. The design of these vehicles is based on successful civilian off road versions specially adapted for military use. They are powered by TATRA air-cooled diesel engines compliant with Euro II and Euro III emission standards but can accept liquid-cooled engines from other manufacturers. The ARMAX product line comprises a variety of versions based upon 4x4, 6x6 and 8x8 platforms. The standard equipment of TATRA ARMAX tactical military truck system includes: all wheel drive, axial and inter-axial differential locks, ABS system, CTIS system enabling re-inflation of tires during the drive in boggy terrain, 14.00 R20 military tactical tires, engine operation possible with fuel complying with NATO standards, combat engineering equipment, camouflage and convoy vehicle lighting, vehicle radio-shielding as per NATO standards and special protective surface finish.

Ground Specifications
Max Speed 105.0 km/h
Range 1000.0 km
Overview (Deagel)
Group Military Trucks
Status Active
Also Known As T 815-25RR45/50T, T 815-26OR45/451, T 815-26WR45/10T, T 815-26WR45/11T, T 815-26WR45/12T, T 815-26WR45/13T, T 815-26WR45/14T
Origin Czechia
Contractor TATRA
Total Production ?
Specifications (Deagel)
Wheel Drive 4
Wheels 4
Degree — Approach Angle 36 °
Degree — Departure Angle 37 °
Dimensions — Ground Clearance 360 millimeter
Dimensions — Length 7.4 meter
Dimensions — Track 2.0 meter
Dimensions — Wheelbase 4.5 meter
Dimensions — Width 2.5 meter
Energy — Max Torque 1,570 Nm
Mass — Cargo 9,200 kilogram
Mass — Max Gross Train Weight 41,000 kilogram
Mass — Max Weight 17,000 kilogram
Percentage — Gradient 100 %
Percentage — Side Slope 67 %
Performance — Ditch Crossing Ability 0.90 meter
Performance — Fording Depth 1.2 meter
Performance — Max Range 1,000 kilometer
Performance — Step Climbing Ability 0.50 meter
Performance — Turning Radius 11.5 meter
Power — Power 255 kW
Speed — Top Speed 105 kph
Volume — Fuel Tank Capacity 320 liter
Variants
Variant 1 ARMAX 4x4
Variant 2 ARMAX 6x6
Variant 3 ARMAX 8x8
Details
Country of Origin Czech Republic
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.4 m
Width
2.5 m
Height
Weight
41000 kg
