ARK E35 Chinese Unmanned Aerial Vehicle (UAV)
ARK E35
VTOL Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
ARK E35 Chinese Unmanned Aerial Vehicle (UAV)
Designation
ARK E35
Alternate Designation
ARK E35
Equipment Type
VTOL Unmanned Aerial Vehicle (UAV)
Manufacturer
Shenzhen Skylab M&C Technology Company
Date of Introduction
2021
Description
The ARK E35 Chinese Unmanned Aerial Vehicle (UAV) is a compound-wing heavy-duty inspection UAV, which has the characteristics of fully automatic flight, ultra-long range, large cargo capacity, etc., and can perform autonomous cruise missions. The UAV supporting systems include an operation control platform, interconnected communication channels, and well-developed ground facilities.
Air & Air Defense Specifications
Engine
Electric
Range
120.0 km
Endurance
160.00 hrs
Wingspan
3.50 m
Payload Capacity
10 kg
System
Alternate Designation
ARK E35
Type
Vertical Take-Off and Landing (VTOL)
Manufacturer
Shenzhen Skylab M&C Technology Company
Crew
Unmanned
Payload Capacity
10 kg
Launching System
Vertical Take-Off and Landing (VTOL)
Recovery System
Vertical Take-Off and Landing (VTOL)
Operating Temperature
-20~45℃
Dimensions
Length
1.8 m
Wingspan
3.5 m
Height
0.61 m
Maximum Takeoff Weight
33.5 kg
Automotive
Engine Name
INA
Engine Type
Electric
Engine Power
INA
Maximum Speed
INA
Cruising Speed
79 km/h
Service Ceiling
INA
Maximum Range
120 km
Endurance
160 min
Image Sources
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
A
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.8 m
Width
—
Height
0.61 m
Weight
33.5 kg
Operators (1)
China
