BOXER SKYRANGER 30 German Infantry Fighting Vehicle (IFV)

BOXER SKYRANGER 30

Infantry Fighting Vehicle (IFV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
BOXER SKYRANGER 30 German Infantry Fighting Vehicle (IFV)
Designation
BOXER SKYRANGER 30
Alternate Designation
BOXER SKYRANGER 30
Equipment Type
Infantry Fighting Vehicle (IFV)
Manufacturer
Rheinmetall
Date of Introduction
2024
Description

The BOXER SKYRANGER 30 is a German Infantry Fighting Vehicle (IFV) designed to effectively defend against drone attacks and other aerial threats in contemporary scenarios. This highly mobile air defense system features integrated active search and passive tracking sensors. Equipped with both guns and missiles, it serves as a powerful autonomous shooter capable of engaging various modern battlefield threats, particularly focusing on small uncrewed targets. The BOXER SKYRANGER 30 combines superior firepower with the necessary dynamics and elevation to successfully target highly agile single or swarming threats that perform loitering, pop-up, or dive attacks. Rheinmetall offers the most lethal, mobile, and well-protected wheeled air defense platform available. Over 1,300 BOXER vehicles in twenty different versions are currently under contract with four NATO member states: Germany, Lithuania, the Netherlands, and the United Kingdom, as well as Australia. To date, Germany and Austria have ordered a total of 55 SKYRANGER 30 units.

Ground Specifications
Crew 2
Mobility Type Wheeled (8x8)
Main Weapon 30mm
Engine Multi-Fuel (780 hp)
NBC Protection Yes
Max Speed 65.0 km/h
Range 1050.0 km
System
Alternative Designation BOXER SKYRANGER 30
Type Infantry Fighting Vehicle (IFV)
Manufacturer Rheinmetall
Configuration 8x8
Crew 2 ea
Passenger Capacity 5 ea
Air Transportation Aeroplane C-17A Globemaster Aircraf
Dimensions
Length 8,000 mm
Width 3,000 mm
Height 3950 mm
Weight, Combat 39,500 kg
Automotive
Engine Name MTU 8V199 V8
Engine Type multi fuel engine
Engine Power 780 hp
Maximum Range 1,050 km
Maximum Land Speed 65 km/h
Amphibious No
Gradient 60%
Side Slope 30%
Vertical Step 0.70m
Trench 2.0m
Fording 1.40 m
Main Weapon System
Turret Remote controlled gun/missile turret
Radar 360° AESA search radar and Electro-optical sensor package
Type 1 x 30mm Oerlikon Revolver Cannon® KCE-ABM
Basic Load up to 300x 30mm x 173
Short Range Air Defense (SHORAD) Missiles
Type 4 x VSHORAD missiles
Protection
Hull Armor Medium-calibre cannons, HMG and small arms
Turret Armor Medium-calibre cannons, HMG and small arms
Applique Armor INA
Blast and Mine Protection Anti-tank mines, IEDs and EFP mines
ATGM and RPG Protection Optional APS and bomblet protection
NBC Protection Yes
Smoke Equipment 2x 10 Rosy smoke grenade launchers
Details
Country of Origin Germany
Category Land
Land
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8 m
Width
3 m
Height
3.95 m
Weight
39500 kg
Operators (6)
Germany
United Kingdom
Australia
Austria
Lithuania
Netherlands
