Pandur I Austrian 6x6 Armored Personnel Carrier (APC)
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
Pandur I Austrian 6x6 Armored Personnel Carrier (APC)
Designation
—
Alternate Designation
—
Equipment Type
—
Manufacturer
Steyr-Daimler-Puch
Date of Introduction
1996
Description
The Pandur I is an APC developed and produced by the Austrian company Steyr-Daimler-Puch Spezialfahrzeuge (SSF). It was developed during the 1980s as a private venture, based on the Pegaso BMR-600 design.[1] In 2003, General Dynamics took over Steyr-Daimler-Puch which is now part of General Dynamics European Land Systems (GD ELS), which is also the parent company of MOWAG, Santa Bárbara Sistemas and GD ELS – Germany. The baseline vehicle is armed with a 12.7 mm (.50 cal) heavy machine gun. Its modular design allows it to be fitted with a variety of weapon systems, including a 20 mm autocannon and an armored two-man 90 mm gun turret.
Ground Specifications
Crew
2
Mobility Type
Wheeled (6x6)
Main Weapon
12.7 mm (.50 cal) heavy machine gun
Engine
6-Cylinder Turbocharged Diesel (260 hp)
Max Speed
100.0 km/h
Range
700.0 km
Variants
Pandur 1
Basic version as in the description
Belgian Pandur
Belgian SMAS radio, NBC protection, armed with 12.7-mm & 7.62-mm machine guns
Amphibious Pandur
Electric bilge pumps, closed air intakes-capable of 11 km/h in water
Pandur II
Pandur II
Pandur Anti-Aircraft
Twin 20-mm cannon or SANTAL SAM in turret
Pandur ATGM Carrier
HOT AT missile in a Euromissile UTM 800 launcher or a TOW AT missile in a Kvaerner-Eurkea turret; additional missiles stored in the hull
Pandur Armored Recon/Fire Support Vehicle (FSV)
2-man LCTS turret with a Cockerill 90-mm Mk 8 gun or a Giat TS-90 turret with a 90-mm CN90F4 gun or Cockerill CSE90 turret with an Mk III 90-mm gun
Pandur Mechanized Infantry Combat Vehicle (MICV)
MGTS with a choice of armaments: 12.7-mm M2 & 7.62-mm MGs; 30-mm M230 chain gun & 7.62-mm MG; or 40-mm AGL & 12.7-mm MG
Pandur Mortar Carrier
In the passenger compartment, there is an 81-mm or 120-mm mortar mounted on a turnatable
Command & Control Vehicle
For C2 operations
Armored Recovery/Repair Vehicle
For vehicle recovery operations
System
Alternative Designations
NA
Manufacturer
Steyr-Daimler-Puch
Crew
2 (driver, commander) ea
Passengers
8 ea
Dimensions
Length
5.70 m
Width
2.50 m
Height
1.82 m
Ground clearance
0.43 m
Wheels, First Axle
2.15 m
Wheels, Second Axle
2.15 m
Wheels, Third Axle
2.16 m
Weight, Unloaded
10,300 kg
Weight, Combat
13,500 kg
Weight, Maximum Payload
3,200 kg
Automotive
Engine Name
1 x Steyr WD 612.95
Engine Type
6-cylinder turbocharged water-cooled diesel with air-intake cooling
Engine Power
260 hp at 2,400 rpm
Power-to-Weight Ratio
19.25 hp/metric ton at maximum weight
Transmission
Allison MT-653 DR, five speeds, torque converter, lock-up clutch
Cruising Range
700 km
Speed (Max Road)
100 km/h
Speed (Max Off-Road)
INA
Speed (Average cross-country)
INA
Speed (Max Swim) (km/h)
N/A
Grading
70 deg
Side Slope
40 deg
Vertical Step
0.5 m
Trench
1.1 m
Fording
1.2 m
Fuel Capacity
275 liters
Suspension
6 x 6 independent
Turning Radius
8.50 m
Main Weapon System
System
Name
NSV 12.7mm Heavy Machine Gun
Type
12.7mm Heavy Machine Gun
Manufacturer
"Metallist", Uralsk, Kazakh SSR, Crvena ZastavaSerbia
In Service
1971-Present
Proliferation
Widely Proliferated
Length
1,560 mm
Weight, Gun Only
25 kg
Weight, Gun and Tripod
41 kg
Weight, 50 Round Belt
11 kg
Action
Gas-operated
Rate of Fire
700–800 rounds/min
Effective Firing Range vs Air Targets
1,500 m
Effective Firing Range vs Ground Targets
2,000
Feed System
50-round belt
Sights
Iron sights
Ammunition
Type
Rifle
Caliber
12.7mm
Cartridge
12.7×108mm
Muzzle Velocity
845 m/s
Basic Load
1,200 ea
Fire Control
Fire Control System
No
FCS Name
INA
Night Vision
Optional
Navigation
Optional
Protection
Armor (turret front) (mm)
Protects against 7.62-mm AP rounds at 30 m
Applique Armor (mm)
INA
Explosive Reactive Armor (mm)
INA
Active Protection System
INA
Self-entrenching Blade
No
NBC Protection System
Available
Smoke Equipment
6 Smoke grenade launchers
Survivability Equipment
No
Details
Country of Origin
Austria
Category
Land
Land
Filter Label
P
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
5.7 m
Width
2.5 m
Height
1.82 m
Weight
13500 kg
Operators (5)
United States
Austria
Belgium
Gabon
Kuwait
