M30 GMLRS

M30 GMLRS

Rockets
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
M30 GMLRS
Designation
M30 GMLRS
Alternate Designation
70km Sniper (British Army nickname), M30A1, M30A2, XM30
Equipment Type
Rockets
Manufacturer
Lockheed Martin, MBDA
Date of Introduction
2005
Description

The maximum range of the GMLRS will be in excess of 60 km (approx. 70 kilometers current estimates) and the payload will be reduced to only 404 M77 DIPCM submunitions. The GMLRS outstanding accuracy will be measurable in meters. GMLRS along with other improvements will allow the deployment of the M270 MLRS weapon system for several decades to come. The European Fire Control System (EFCS) was developed to effectively fire and control the new GMLRS rocket provided by Lockheed-Martin. EFCS was developed and will be integrated into existing European MLRS systems in partnership between EADS, Thales (France and Italy) and Krauss-Maffei Wegmman. Field testing was scheduled to start in early 2005 with the first EFCS integrated into the M270 launcher. Production EFCS-equipped launchers is expected to commence in 2006. Lockheed-Martin and MBDA team are considering new variants and further enhancements for the GMLRS rocket family. Europe-based MBDA in conjunction with Aerojet are offering a variant of BANG warhead to equip GUMLRS rocket. MBDA proposing a laser guided M30 variant for improved accuracy. Lockheed-Martin was awarded the third low rate initial production (LRIP) contract valued at $108 million for 1,014 GMLRS rockets armed with Dual Purpose Improved Conventional Munitions (DPICMs) on January 31, 2005. Rocket deliveries for this assignment were scheduled to be completed by April 30, 2007. Previously, Lockheed-Martin was awarded the first LRIP contract for 170 (156? other sources) rockets valued at $24 million in June 2003 and the second contract for 840 missiles worth $85 million in February 2004. GMLRS production is expected to extend beyond 2020. The first LRIP contract was completed in May 2005. In August 2005, the United Kingdom became officially the first international customer for the GMLRS rocket weapon. Lockheed-Martin was awarded a $55 million Foreign Military Sales (FMS) contract to deliver GMLRS with the Dual Purpose Improved Conventional Munitions (DPICM) warhead to the British Army through March 2007.

Ground Specifications
Max Speed 3087.0 km/h
Range 70.0 km
Overview (Deagel)
Group Rockets
Status Active
Also Known As 70km Sniper (British Army nickname), M30A1, M30A2, XM30
Origin France, Germany, Italy, United Kingdom, United States of America
Contractors Lockheed Martin, MBDA
Initial Operational Capability (IOC) 2005
Total Production 43,882
Unitary Cost USD $90,000
Specifications (Deagel)
Dimensions — Caliber 227 millimeter
Dimensions — Length 4 meter
Mass — Warhead 90 kilogram
Mass — Weight 308 kilogram
Performance — Max Range 70,000 meter
Speed — Top Speed 2.5 mach
Variants
Variant 1 GMLRS ER
Variant 2 M30 GMLRS
Variant 3 M31 GUMLRS
Variant 4 GMLRS+
Variant 5 ER GMLRS
Details
Country of Origin France
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
4 m
Width
Height
Weight
308 kg
Operators (19)
United States
France
Germany
United Kingdom
Israel
Italy
Japan
South Korea
Ukraine
Poland
Australia
Bahrain
Estonia
Finland
Jordan
Lithuania
Romania
Singapore
United Arab Emirates
