2B24 Russian 82mm Mortar
2B24
Multiple Launch Rocket System (MLRS)
Other
Basic Information
Name
2B24 Russian 82mm Mortar
Designation
2B24
Alternate Designation
2B24
Equipment Type
Multiple Launch Rocket System (MLRS)
Manufacturer
JSC CRI Burevestnik
Date of Introduction
2010
Description
The 82 mm 2B24 mortar is also in Rosoboronexport`s mortars portfolio. The mortar is designed to suppress and destroy enemy`s manpower and weapon systems. It should be noted that 2B24 features enhanced maneuverability and combat effectiveness. The mortar can be installed on various types of wheeled or tracked chassis. According to the specifications, 2B24 has a firing range of 100-6,000 m, a firing rate of 20 rounds per minute, a weight of 45 kg, and a crew of five servicemen.
Ground Specifications
Crew
5
Mobility Type
Towed
Main Weapon
82mm mortar
Range
6000.0 km
System
Alternative Designation
2B24
Type
Mortar
Caliber
82 mm
Crew
5 ea
Emplacement Time
30 seconds maximum
Displacement Time
30 seconds maximum
Maximum Effective Range
6,000 m
Minimum Effective Range
100 m
Transportation
Is man portable for short distances by the 5 man squad. Can be transported by a single ATV. Can be mounted on combat vehicles to be fired from a mounted position.
Dimensions
Length
INA
Width
INA
Height
INA
Weight, Combat
45 kg
Weight, Barrel
INA
Weight, Baseplate
INA
Weight, Bipod
INA
Weight, Sight
INA
Armament
System
Loader Type
Muzzle loaded
Max Rate of Fire
20 rds/min
Sustain Rate of Fire
INA
Max Elevation
85° deg
Min Elevation
45° deg
Traverse Range
±4° (without bipod repositioning); 360° (with bipod repositioning)
Ammunition
Type
HE, Smoke, Illum, HE Frag
Caliber
82 mm
Muzzle Velocity
320 m/s
Fuse Type
INA
Basic Load
INA
Effective Ranges
100 m - 6,000m
Armor Penetration
INA
Weight of Round
INA
Note:
HE Frag Rounds: 3-O-26, O-832 D, O-832 DU and 3-O-12. Other types of mortar rounds can also be used to perform certain tactical and fire tasks: smoke (D-832DU and D-832 A), illuminating (S-832 S) and leaflet (A-832 A) rounds.
Fire Control
Computerized FCS
No
Direct Fire
INA
Indirect Fire
Yes
Collimator
Yes
Image Sources
Notes
https://roe.ru/esp/catalog/las-fuerzas-de-tierra/sistemas-de-misiles-mlrs-atra-y-ca%C3%B1ones-de-artiller%C3%ADa-de-campo/2b24/; https://militaryleak.com/2022/07/23/jsc-cri-burevestnik-to-supply-82mm-2b24-mortars-for-russian-ministry-of-defence/; https://militaryleak.com/2022/07/23/jsc-cri-burevestnik-to-supply-82mm-2b24-mortars-for-russian-ministry-of-defence/;
Details
Country of Origin
Russia
Category
Non-Self Propelled Mortar Systems
Land > Infantry Weapons > Non-Self Propelled Mortar Systems
Filter Label
2
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
45 kg
Operators (2)
Russia
Ukraine
