LJ-7
LJ-7
Anti-Tank Guided Missiles
Basic Information
Name
LJ-7
Designation
LJ-7
Alternate Designation
Blue Arrow 7, Lan Jian 7
Equipment Type
Anti-Tank Guided Missiles
Manufacturer
China Aerospace Science & Technology Corporation CASC
Date of Introduction
2014
Description
The Lan Jian 7 or LJ-7, also known as the Blue Arrow 7, is an anti-tank missile featuring an increased warhead to achieve an armor penetration of 1,400 mm. The LJ-7 features a semi-active laser guidance system and a maximum range of 7 kilometers. The LJ-7/Blue Arrow 7 entered service in the mid 2010s and is expected to equip the CH-4 and CH-5 unmanned air vehicles.
Ground Specifications
Range
7.0 km
Overview (Deagel)
Group
Anti-Tank Guided Missiles
Status
Active
Also Known As
Blue Arrow 7, Lan Jian 7
Origin
China
Contractor
China Aerospace Science & Technology Corporation CASC
Initial Operational Capability (IOC)
2014
Total Production
?
Specifications (Deagel)
Dimensions — Diameter
170 millimeter
Dimensions — Length
1.8 meter
Mass — Weight
46 kilogram
Percentage — Hit Probability
80 %
Performance — Max Range
7,000 meter
Performance — Min Range
2,000 meter
Performance — Piercing in Armor
1,400 millimeter
Temperature — Max Operating Temperature
50 ° Celsius
Temperature — Min Operating Temperature
-40.00 ° Celsius
Time — Service Life
10 year
Variants
Variant 1
AR-1
Variant 2
CM-502KG
Variant 3
LJ-7
Details
Country of Origin
China
Sources
deagel.com: https://www.deagel.com/x/x/a003469
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.8 m
Width
—
Height
—
Weight
46 kg
Operators (2)
China
Saudi Arabia
