H100 Chinese Unmanned Aerial Vehicle (UAV)

H100

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
H100 Chinese Unmanned Aerial Vehicle (UAV)
Designation
H100
Alternate Designation
H100
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Xi'an Supersonic Aviation Technology Co (SAT_
Date of Introduction
2022
Description

The H100 Chinese Unmanned Aerial Vehicle (UAV) represents a high-performance, multi-purpose dual-rotor helicopter drone that is equipped with autonomous flight, take-off, and landing capabilities. This UAV is extensively utilized for a range of applications, including logistical support and the transportation of various materials. Specifically designed for the professional transport of diverse equipment and items, this unmanned cargo helicopter excels due to its exceptional maneuverability, allowing it to operate effectively in challenging environmental conditions. It is particularly well-suited for long-range operations of up to 300 kilometers in complex terrains, such as mountainous regions, forests, plateaus, and other specialized environments. The H100 drone can undertake a variety of transportation tasks without reliance on traditional airports or runways. Its ability to take off and land vertically at designated locations enhances operational efficiency and convenience. Presently, this drone is employed in the transportation of medical supplies, the execution of search and rescue operations, and several other industry applications. It is capable of carrying an array of airborne equipment, such as photoelectric pods, infrared (IR) sensors, laser scanners, and other specialized instruments. Designed for low-altitude flight and equipped with advanced pods, this UAV provides clear and accurate ground observations while maintaining close proximity to efficiently accomplish its transportation tasks.

Air & Air Defense Specifications
Max Speed 120.0 km/h
Cruise Speed 60.0 km/h
Range 300.0 km
Endurance 3.00 hrs
Service Ceiling 3000 m
Payload Capacity 120 kg
System
Alternate Designation H100
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Xi'an Supersonic Aviation Technology Co (SAT_
Payload Capacity 120 kg
Payload Design photoelectric pods, infrared (IR) sensors, laser scanners and other airborne equipment or any special design available
Data Link 30km, 50km, 100km, 180km, high-definition real-time data and video transmission are optional.
Electro-Optical Pod For Reconnaissance, surveillance, search and rescue, target positioning, identification, tracking, and navigation.
Ground Control Station Support handheld ground station/box ground station/vehicle ground station/remote command.
Ground Communication Station Air-to-ground communication station/network communication station/satellite communication station.
Dimensions
Length 3,000 mm
Width 1,000 mm
Height 1,300 mm
Maximum Takeoff Weight 300 kg
Automotive
Engine Name INA
Engine Type INA
Engine Power 65 HP, water cooling
Maximum Speed 120 km/h
Cruise Speed 60-120km/h
Maximum Range 300 km
Service Ceiling 3,000 m
Endurance 3 hours
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
H
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
3 m
Width
1 m
Height
1.3 m
Weight
300 kg
Operators (1)
China
