FREMM GP

FREMM GP

Frigates
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
FREMM GP
Designation
FREMM GP
Alternate Designation
Carlo Bergamini
Equipment Type
Frigates
Manufacturer
Orizzonte Sistemi Navali, Fincantieri, Leonardo, SELEX ES
Date of Introduction
2013
Description

The Italian Navy FREMM GP (General Purpose) class frigate built by Fincantieri has been designed to carry out ASW and ASuW missions as well as delivering commandos onto enemy shores using two large Rigid Inflatable Boats (RIBs). The propulsion plant will have a CODLAG (COmbined Diesel eLectric And Gas) configuration featuring one Avio-GE LM2500+G4 gas turbine, two electrical motors and four diesel generating units. The Italian Navy has ordered six FREMM GP frigates with the first one to be commissioned in 2013. The FREMM GP weapon system includes a 127mm (127/64) naval gun system at the bow firing Vulcano precision long-range projectiles, a 76mm Super Rapid naval gun system at the stern, 16 Aster 15 Surface-to-Air Missiles (SAM) and Teseo missile system with capacity for Otomat anti-ship missile and Milas anti-submarine missile. Besides, the ship provided with the NA-25 DARDO-F fire control system, Empar multi-function radar, SAAM IT air defense system and the Sylver A-50 vertical launch system. Besides, these ships can operate two helicopters (two NH90 Caiman or 1 NH90 and 1 EH101) utilizing the aft flight deck and hangar.

Naval & Littoral Specifications
Crew 145
Displacement 6500.00 tonnes
Beam 19.70 m
Draft 5.00 m
Max Speed 27.0 knots
Overview (Deagel)
Group Frigates
Status Active
Also Known As Carlo Bergamini
Origin Italy
Contractors Orizzonte Sistemi Navali*, Fincantieri, Leonardo, SELEX ES
Initial Operational Capability (IOC) May 2013
Total Production 14
Unitary Cost USD $500 million
Specifications (Deagel)
Crew 145
Number of Aircraft 2
Number of Engines 1
Number of Weapons 24
Troops 200
Dimensions — Beam 19.7 meter
Dimensions — Draft 5 meter
Dimensions — Length 144 meter
Dimensions — Main Gun Caliber 127 millimeter
Mass — Full Displacement 6,500 ton
Performance — Max Range 6,000 nautical mile
Power — Boost Power 32 MW
Speed — Cruise Speed 15 knot
Speed — Top Speed 27 knot
Time — Mission Endurance 45 day
Time — Service Life 30 year
Gear (Deagel)
Item 1 Anti-Ship Missiles: Teseo Mk2/A (8)
Item 2 Anti-Ship Missiles: Teseo Mk2/E (8)
Item 3 ASW Helicopters: EH101 Merlin (1)
Item 4 ASW Helicopters: NH90 NFH (2)
Item 5 Decoy Systems: NGDS (1)
Item 6 Missile Launchers: Sylver (16)
Item 7 Naval Gun Systems: 127/64 Lightweight (1)
Item 8 Naval Gun Systems: 76/62 Super Rapid (1)
Item 9 Projectiles: Vulcano
Item 10 Radar Systems: Empar (1)
Item 11 Sea-Based Air Defense Systems: SAAM IT
Item 12 Ship Power Plants: LM2500+G4 (1)
Item 13 Surface-to-Air Missiles: Aster 15 (16)
Variants
Variant 1 FREMM ASM
Variant 2 FREMM GP
Variant 3 FREMM ASW
Variant 4 FREMM FREDA
Variant 5 FREMM EVO
Details
Country of Origin Italy
Category Frigates
Naval > Frigates
Sources

deagel.com: https://www.deagel.com/x/x/a000420

Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
144 m
Width
19.7 m
Height
—
Weight
6500000 kg
Related Equipment (1)
Variant of

FREMM ASM

FREMM ASM

FrigatesFrance
View details
Operators (4)
Italy
Egypt
Greece
Indonesia
