CV9035 MkIII

CV9035 MkIII

Tracked Armored Vehicles
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
CV9035 MkIII
Designation
CV9035 MkIII
Alternate Designation
CV9035 MkIIIC, CV9035 NL
Equipment Type
Tracked Armored Vehicles
Manufacturer
Alvis Plc, United Defense
Date of Introduction
2004
Description

The CV9035 MkIII is the next generation of the CV9030 infantry fighting vehicle. It will feature a Bushmaster III 35mm 50-caliber cannon as main armament to counter emerging threats with a computerized fire control solution, new programmable ammunition, a commander's independent sight achieving hunter-killer capability, higher protection against top-attack munitions and mines through a new armor package, third generation FLIR, and a defensive aids suite with laser warning receivers and smoke launchers. The CV9035 MkIII program started in 2001 and completed its development, becoming available for production, in mid-2004. Alvis Hägglunds plans to integrate the individual improvements featured in CV9035 MkIII into previous generations of CV90 armored platform such as CV9030 and CV9040. Overall, CV9035 features enhanced firepower, survivability, mobility, ergonomics and advanced electronic architecture with implemented C4I systems. In June 2004, Patria Hägglunds was awarded a €120 million contract for 45 additional CV9030 FIN infantry fighting vehicles with deliveries due in 2006 and 2007. It is likely that the 45 CV90s ordered by Finland will be supplied in the CV9035 Mk III standard. Following BAe Systems acquisition of Alvis the new company/business unit responsible for the CV90 project was named Land Systems Hagglunds. On December 10, 2004, Land Systems Hagglunds received a €749 million contract for the production of 184 CV9035 infantry fighting vehicles. CV9035 was chosen by the government of Netherlands after extensive competitive evaluation and testing under the Dutch Infantry Fighting Vehicle program. The Netherlands Army will be the end customer for these vehicles and the Dutch defense will be strongly involved in the production phase of the program. Deliveries will start in 2007 and will last until 2010. In mid-December 2005 the Danish Army ordered 45 CV9035 Mk III infantry fighting vehicles worth £123 million becoming the fourth customer for the CV90 version equipped with a Bushmaster III 35/50 canon. The contract also included Danish company Hydrema Export A/S as a partner to BAE Systems for the production of the vehicles.

Ground Specifications
Crew 3
Troop Capacity 7
Mobility Type Tracked
Main Weapon Bushmaster III 35mm 50-caliber cannon (35mm)
Max Speed 70.0 km/h
Range 600.0 km
Overview (Deagel)
Group Tracked Armored Vehicles
Status Active
Also Known As CV9035 MkIIIC, CV9035 NL
Origin Sweden
Contractors Alvis Plc, United Defense
Initial Operational Capability (IOC) 2004
Total Production 483
Unitary Cost USD $15 million
Specifications (Deagel)
Crew 3
Rolling Rubber Wheels 7
Troops 7
Dimensions — Height 2.8 meter
Dimensions — Length 6.6 meter
Dimensions — Main Gun Caliber 35 millimeter
Dimensions — Width 3.2 meter
Mass — Combat Weight 28,000 kilogram
Mass — Empty Weight 24,000 kilogram
Performance — Max Range 600 kilometer
Power — Power 600 shp
Speed — Top Speed 70 kph
Gear (Deagel)
Item 1 ATGM & RPG Countermeasures: Iron Fist (1)
Item 2 ATGM & RPG Countermeasures: LEDS-50
Item 3 Medium Caliber Cannons: M242 Bushmaster III (1)
Item 4 Optronic Systems: Claire
Item 5 Optronic Systems: UTAAS (1)
Item 6 Weapon Stations: Protector RS4 (1)
Variants
Variant 1 CV9040
Variant 2 CV9040C
Variant 3 CV9040 AAV
Variant 4 CV90120
Variant 5 CV90 FOV
Variant 6 CV90 FCV
Variant 7 CV90105
Variant 8 CV9030
Variant 9 CV9030 MkII
Variant 10 CV9035 MkIII
Variant 11 CV9030 COM
Variant 12 CV90 AMOS
Variant 13 CV90 Sting
Variant 14 CV90 Armadillo
Variant 15 CV90 FMV
Variant 16 CV90 MkIV
Variant 17 CV90 CEV
Details
Country of Origin Sweden
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.6 m
Width
3.2 m
Height
2.8 m
Weight
28000 kg
Operators (7)
Ukraine
Sweden
Denmark
Estonia
Finland
Netherlands
Switzerland
