Jang Bogo Class South Korean Diesel-Electric Attack Submarine
Jang Bogo Class
Diesel-Electric Submarine
Other



Basic Information
Name
Jang Bogo Class South Korean Diesel-Electric Attack Submarine
Designation
Jang Bogo Class
Alternate Designation
Jang Bogo Class
Equipment Type
Diesel-Electric Submarine
Manufacturer
—
Date of Introduction
1993
Description
The Jang Bogo-class submarine is a variant of the Type 209 diesel-electric attack submarine initially developed by Howaldtswerke-Deutsche Werft (HDW) of Germany, intended for service with the South Korean Navy and Indonesian Navy. A Daewoo (DSME)-upgraded model of the Jang Bogo class Type 209 is being independently exported by Korea to Indonesia in 2012, after a series of heavy competitions from Russian, French, and German-Turkish consortiums including from Germany's original Type 209. The variant is being considered for possible purchase by Thailand as well, as both newly built and second-hand options. The class is named for ancient Korean maritime figure Jang Bogo.
Naval & Littoral Specifications
Crew
36
Beam
6.50 m
Draft
6.20 m
Variants
Jang Bogo
Commissioned: 1993
Status: Active
Lee Chun
Commissioned: 1994
Status: Active
Choe Museon
Commissioned: 1995
Status: Active
Park Wi
Commissioned: 1996
Status: Active
Lee Jongmoo
Commissioned: 1997
Status: Active
Jung Woon
Commissioned: 1998
Status: Active
Yi Sun-sin
Commissioned: 2000
Status: Active
Na Dae-yong
Commissioned: 2000
Status: Active
Yi Eokgi
Commissioned: 2001
Status: Active
System
Alternative Designation
Jang Bogo Class
Type
Diesel-Electric Attack Submarine
Builder
Howaldtswerke-Deutsche Werft
Daewoo Shipbuilding & Marine Engineering
Crew
36
Dimensions
Length
64.4 m
Beam
6.5 m
Draft
6.2 m
Displacement, Standard
1,810 tons (submerged)
Propulsion System
Engine Name
4 x MTU Type 8V396 SE
Electric Motor Name
1 x Siemens electric motor
Engine Type
Diesel-Electric
Engine Power
4,500 kW (6,100 shp)
Maximum Speed, Submerged
21 km/h (11.5 knots)
Maximum Speed, Submerged
42 km/h (22.5 kn)
Maximum Range, Surfaced
20,000 km (11,000 nautical miles) at 19 km/h (10 kn)
Maximum Range, Snorkeling
15,000 km (8,000 nmi) at 19 km/h (10 kn) snorkeling
Maximum Range, Submerged
740 km (400 nmi) at 7 km/h (4 kn) submerged
Endurance
50 Days
Armament
Note
8 × 21-inch (533 mm) torpedo tubes,
14 x torpedoes; optional UGM-84 Harpoon integration
Protection
Active Protection System
INA
Countermeasures
INA
NBC Water Washdown System
INA
Details
Country of Origin
South Korea
Category
Submarines
Naval > Submarines
Filter Label
J
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
64.4 m
Width
—
Height
—
Weight
—
Operators (1)
South Korea
