Qasef-1 Iranian Reconnaissance and Loitering Munition Unmanned Aerial Vehicle (UAV)
Qasef-1
Loitering Munition UAV
Other




Basic Information
Name
Qasef-1 Iranian Reconnaissance and Loitering Munition Unmanned Aerial Vehicle (UAV)
Designation
Qasef-1
Alternate Designation
Qasef-1
Equipment Type
Loitering Munition UAV
Manufacturer
HESA
Date of Introduction
2016
Description
The Qasef-1 loitering munition is based on the Ababil-2 airframe and has a 30-kg warhead. It has been solely operated by Yemeni Houthis, who have mostly used it to attack the radar components of MIM-104 Patriot surface-to-air missiles. The Qasef-1 has been in use since late 2016 and some examples have been intercepted in transit to Yemen. It is possibly a renamed or modified Ababil-T with an installed explosive charge or a warhead. The Houthis claim that they manufacture Qasef-1s themselves, but this claim has been disputed and there is widespread suspicion that it is Iranian-built.
Air & Air Defense Specifications
Engine
twin-cylinder piston engine (25 hp)
Max Speed
370.0 km/h
Range
120.0 km
Service Ceiling
3000 m
Wingspan
3.25 m
System
Alternate Designation
Qasef-1
Type
Reconnaissance and Loitering Munition Drone
Manufacturer
Iran Aircraft Manufacturing Industrial Company (HESA) - Iran
Crew
Unmanned
Dimensions
Length
2.88 m
Wingspan
3.25 m
Height
0.9 m
Empty Weight
30 kg
MTOW
85 kg
Automotive
Engine Name
1 x WAE-342
Engine Type
twin-cylinder piston engine
Engine Power
25 hp and driving a two-bladed propeller unit at the rear of the fuselage in pusher arrangement.
Maximum Speed
370 km/h
Range
120 km/h
Service Ceiling
3,000 m
Armament
Note
1 x 30 kg warhead with Impact Detonation
Image Sources
Notes
https://www.tasnimnews.com/en/news/2018/12/06/1892778/yemeni-forces-launch-drone-attack-against-saudi-backed-forces-in-eastern-sana-a; https://parstoday.ir/en/news/west_asia-i90374-yemeni_drone_strikes_saudi_mercenaries%E2%80%99_command_center_in_bayda; https://worldmilitaryintel.blogspot.com/2013/05/yemen-yemen-capitaladen-about89500.html; https://ifpnews.com/yemeni-army-unveils-four-new-drones/;
Details
Country of Origin
Iran
Category
UAVs
Air > UAVs
Filter Label
Q
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
2.88 m
Width
3.25 m
Height
0.9 m
Weight
30 kg
Operators (2)
Iran
Yemen
