Project 11356

Project 11356

Frigates
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Project 11356
Designation
Project 11356
Alternate Designation
Burevestnik, Krivak IV (NATO codename), Project 1135.6, Talwar (Indian Navy name)
Equipment Type
Frigates
Manufacturer
Severnoye Design Bureau, Yantar
Date of Introduction
2003
Description

The Project 11356 frigate ordered by the Indian Navy is equipped with the Shtil-1 medium range air defense system with 24 9M38 missiles and one 3S-14E eight-tube under-deck launcher with eight 3M-54TE/Club-N supersonic anti-ship missiles. In addition, the ship is provided with one 100mm A-190E naval gun with 500 rounds, two Kashtan close-in weapon systems with 64 9M311-1 missiles, a RBU-6000 12-tube anti-submarine warfare (ASW) mortar, and two double 533mm tubes for SET-65K torpedoes. Additional protection is provided with the ship's Electronic Counter-Measures (ECM) and decoy systems. India placed an order for three ships in the late 1990s which were delivered in 2003 and 2004. The Indian government and the government of Russia signed a follow-on contract for the purchase of three additional Project 1135.6 frigates for the Indian Navy on July 14, 2006. These ships were built at Yantar Shipyard in Kaliningrad. The ships were commissioned in 2012 and 2013. These ships feature BrahMos supersonic anti-ship cruise missile instead of the Club-N/3M54TE missile system which was provided to the INS Talwar, INS Trishul and INS Tabar frigates.

Naval & Littoral Specifications
Crew 193
Displacement 4035.00 tonnes
Beam 15.20 m
Draft 4.20 m
Max Speed 30.0 knots
Overview (Deagel)
Group Frigates
Status Active
Also Known As Burevestnik, Krivak IV (NATO codename), Project 1135.6, Talwar (Indian Navy name)
Origin Russia
Contractors Severnoye Design Bureau, Yantar
Initial Operational Capability (IOC) June 18, 2003
Total Production 6
Unitary Cost USD $530 million
Specifications (Deagel)
Ammunition Load 500
Crew 193
Number of Aircraft 1
Number of Weapons 32
Dimensions — Beam 15.2 meter
Dimensions — Draft 4.2 meter
Dimensions — Length 125 meter
Dimensions — Main Gun Caliber 100 millimeter
Mass — Full Displacement 4,035 ton
Performance — Max Range 4,850 nautical mile
Power — Total Combined Power 56,000 hp
Speed — Cruise Speed 14 knot
Speed — Top Speed 30 knot
Time — Mission Endurance 30 day
Gear (Deagel)
Item 1 Anti-Ship Missiles: 3M54TE/Club-N (8)
Item 2 Anti-Ship Missiles: BrahMos (8)
Item 3 Anti-Submarine Rockets: RBU-6000 (1)
Item 4 ASW Helicopters: Ka-27 (1)
Item 5 Maritime Helicopters: Ka-31 (1)
Item 6 Naval Gun Systems: A190E (1)
Item 7 Radar Systems: 3TS-25E (1)
Item 8 Radar Systems: Fregat M2EM (1)
Item 9 Sea-Based Air Defense Systems: Kashtan (2)
Item 10 Sea-Based Air Defense Systems: Shtil-1 (1)
Item 11 Ship Power Plants: DS-71 (2)
Item 12 Ship Power Plants: DT-59 (2)
Item 13 Surface-to-Air Missiles: 9M311-1 (64)
Item 14 Surface-to-Air Missiles: 9M317 (24)
Item 15 Torpedoes: SET-65K (4)
Variants
Variant 1 Project 11356
Variant 2 Project 11356R
Variant 3 Triput
Details
Country of Origin Russia
Category Frigates
Naval > Frigates
Sources

deagel.com: https://www.deagel.com/x/x/a001904

Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
125 m
Width
15.2 m
Height
—
Weight
4035000 kg
Related Equipment (2)
Variant of

Admiral Grigorovich Class (Project 11356 Class) Russian Frigate

FrigateRussia
View details
Variant

Triput

Triput

FrigatesIndia
View details
Operators (1)
India
